Tractor · 2001Unverified

Massey Ferguson 425

Name: Massey Ferguson 425
Brand: Massey Ferguson

Massey Ferguson 425 — 400 Series · 55 hp. Reference specifications; pending source verification.

The Massey Ferguson 425 is a tractor with a rated output of approximately 55 hp, placing it at the lighter end of its class. It was in production from 2001 to 2010. The model features a 4-cylinder diesel liquid-cooled engine, coupled with mechanical front-wheel drive and a hydrostatic transmission. Its operating weight is listed as 5710 to 6327 pounds, making it suitable for operations up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Max power

65 hp

Weight

5710 to 6327 pounds

Catalogue coverage

Variants represented

Richest spec table

88 rows

Recorded power

55 hp

Recorded weight

2590 kg

Transmissions

8-speed sliding spur gear

Production years

2001-2010

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Utility tractorReference

Built in Canoas, BrazilReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (optional)Reference

Steeringhydrostatic powerReference

Wet disc brakesReference

Open operator station. Two-post ROPS optional with available canopy.Reference

Engine

Perkins 3.9L 4-cyl dieselReference

Fuel tank74.9 LReference

Engine48.5 kWReference

Perkins A4.236Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke98 x 127 mmReference

Power48.5 kWReference

Fuel systemdirect injectionReference

Rated RPM2200Reference

Torque235.0 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of CylindersOption 1: 4 cylinder\\nOption 2: 4-cylinderReference

Rated engine speed2,200 RPMReference

Engine torque at rated speedOption 1: 173.3 lb-ft @\\nOption 2: 6/21/1,900 lb-ftReference

Bore and stroke3.875x5.00 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speed sliding spur gearReference

12-speed synchromeshReference

Typesliding spur gearReference

Gears8 forward and 2 reverseReference

TypesynchromeshReference

Gears12 forward and 4 reverseReference

Transmission TypeGearReference

forward and reverse optionsSliding Spur Gear : 8 F and 2 R | Synchromesh : 12 F and 4 RReference

Wheel Drive2 WD | 4 WD (Optional)Reference

PTO & Hydraulics

PTO (claimed)40.8 kWReference

Pressure170.0 barReference

Pump flow42.0 lpmReference

Rear TypeIIReference

Controldraft, position, and response controlReference

Rear PTOliveReference

Rear PTOindependent (optional)Reference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1900Reference

Dimensions

2WD Wheelbase214 cmReference

4WD Wheelbase236 cmReference

Weight5710 to 6327 poundsReference

Front tire7.50-16Reference

Rear tire18.4-30 (2WD)Reference

Standard tires (ag)Front: 7.50-16. Rear: 18.4-30 (2WD)Reference

Standard tires (ag)Front: 12.4-24. Rear: 18.4-30 (4WD)Reference

2WD Length398 cmReference

4WD Length413 cmReference

Height (ROPS)258 cmReference

Height (exhaust)244 cmReference

2WD Shipping weight2590 kgReference

4WD Shipping weight2869 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

General

Make & ModelPerkinsReference

Rollover protective structureTwo-post ROPS optional with available canopy.Reference

Country of manufacturerBrazilReference

Capacities

Capacity236 ciReference

Power

Max Power65 hpReference

Rated Power65 hpReference

PTO

PTO Power54.7 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed540@1,900 RPMReference

Steering & brakes

BrakesWet DiscReference

Steering typeHydrostatic PowerReference

Hydraulics

Pump Rated Output (total)11.1 gpmReference

Maximum operating pressure2,466 psiReference

Rear Hitch category (SAE designation)Category IIReference

Rear Hitch Sensing Typedraft, position, and response controlReference

Dimensions & weight

Wheelbase237 cmReference

Overall Height258.1 cmReference

Height Over ROPS258.1 cmReference

Overall Length413 cmReference

Overall weight2,869.9 kgReference

Wheels & tyres

Rear Wheel Type18.4-30 (2WD) | 18.4-30 (4WD)Reference

Front Wheel Type7.50-16. (2WD) | 12.4-24.(4WD)Reference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
