Tractor · 2004Unverified
Massey Ferguson 430
Massey Ferguson 430 — 400 Series · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
5016 to 6338 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulic (optional)Reference
Two-post foldable ROPS. Cab optional.Reference
Engine
Perkins 3.3L 3-cyl dieselReference
Engine55.2 kWReference
Perkins 1103C 33TReference
turbocharged dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement3.3 LReference
Bore/Stroke105 x 127 mmReference
Power55.2 kWReference
Air cleanerdual dry elementReference
Rated RPM2200Reference
Torque291.0 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchro shuttleReference
Typesynchro shuttleReference
Gears8 forward and reverseReference
Clutch305mm cerametalicReference
Capacities
Fuel48.1 LReference
PTO & Hydraulics
Hydraulic system42.0 LReference
Capacity42.0 LReference
Pressure175.0 barReference
Valves1 or 2Reference
Pump flow52.6 lpmReference
Rear Type2/1Reference
Controldraft, position and response controlReference
Rear lift (at ends)1789 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1789Reference
Dimensions
2WD Wheelbase205 cmReference
4WD Wheelbase212 cmReference
Weight5016 to 6338 poundsReference
Front tire6.00-16Reference
Rear tire13.6-28 (2WD)Reference
Standard tires (ag)Front: 6.00-16. Rear: 13.6-28 (2WD)Reference
Standard tires (ag)Front: 280/70R20. Rear: 13.6-28 (4WD)Reference
2WD Length351 cmReference
4WD Length357 cmReference
Height (ROPS)237 cmReference
Height (Folded ROPS)181 cmReference
Height (cab)237 cmReference
2WD ROPS Operating2275 kgReference
2WD cab Operating2505 kgReference
4WD ROPS Operating2575 kgReference
4WD cab Operating2874 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
