Tractor · 2016Unverified

Massey Ferguson 4610M

Name: Massey Ferguson 4610M
Brand: Massey Ferguson

Massey Ferguson 4610M — Utility tractor · 80 hp. Reference specifications; pending source verification.

The Massey Ferguson 4610M is a tractor with a rated power output of 80 hp, a mid-range figure for its class. It was introduced to production in 2016. The 4610M is equipped with a 3-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a 12-speed gearbox. Its operating weights range from 6845 to 7253 pounds, with a maximum suitable area for operation of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

80 hp

Weight

6845 to 7253 pounds

Catalogue coverage

Variants represented

Richest spec table

56 rows

Recorded power

80 hp

Recorded weight

3104 kg

Transmissions

12-speed partially synchronized

Production years

2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

Two- or four-wheel driveReference

Final drivesinternal planetaryReference

Differential lockmechnical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab available with air-conditioning.Reference

Engine

AGCO Power 3.3L 3-cyl dieselReference

Fuel tank114.7 LReference

Exhaust fluid (DEF)15.9 LReference

Engine73.8 kWReference

AGCO PowerReference

intercooled turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke108 x 120 mmReference

EmissionsTier IVReference

Emission controldiesel exhaust fluid with diesel oxidation catalyst (DOC) (DEF)Reference

Power73.8 kWReference

Maximum Power75.3 kWReference

Fuel systemhigh-pressure common railReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed partially synchronizedReference

18-speed partially synchronizedReference

Typepartially synchronizedReference

Gears12 forward and reverseReference

Clutchwet discReference

Six synchronized gears in two ranges.Reference

Gears18 forward and reverseReference

PTO & Hydraulics

PTO (claimed)59.7 kWReference

Typeopen centerReference

Valves1 to 3Reference

Pump flow66.2 lpmReference

Rear TypeIIReference

Rear lift1500 kgReference

Rear lift1999 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase228 cmReference

Weight6845 to 7253 poundsReference

Length389 cmReference

Width204 cmReference

Height (ROPS)270 cmReference

Height (cab)259 cmReference

4WD ROPS Weight3104 kgReference

4WD Cab Weight3289 kgReference

Flange rear axleReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps95Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
