Tractor · 2016Unverified

Massey Ferguson 4710

Name: Massey Ferguson 4710
Brand: Massey Ferguson

Massey Ferguson 4710 — Utility tractor · 88 hp. Reference specifications; pending source verification.

The Massey Ferguson 4710 is a tractor model, characterised by a rated power of 88 hp, a mid-range figure for its class. It was introduced in 2016. Equipped with a 3-cylinder turbocharged intercooled diesel liquid-cooled engine, the 4710 features four-wheel drive and a 12-speed gearbox. Its operating weight ranges from 7478 to 8644 pounds, making it suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

88 hp

Weight

7478 to 8644 pounds

Catalogue coverage

Variants represented

Richest spec table

85 rows

Recorded power

88 hp

Transmissions

12-speed mechanical shuttle

Production years

2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

FactoriesBrazilReference

FactoriesChinaReference

Original price$47,186 (2018 ROPS 2WD )Reference

Original price$63,694 (2018 Cab 4WD )Reference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Differential lockelectro-hydraulic rearReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

AGCO Power 3.3L 3-cyl dieselReference

Fuel tank104.8 LReference

Engine74.6 kWReference

AGCO Power 33AWICReference

intercooled turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke108 x 120 mmReference

EmissionsTier IVReference

Emission controlselective catalytic reduction with diesel oxidation catalystReference

Power74.6 kWReference

Fuel systemhigh-pressure common railReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders3-cylinderReference

Rated engine speed2,200Reference

Bore and stroke4.252x4.724 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speed mechanical shuttleReference

12-speed power shuttleReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

Typepower shuttleReference

Clutchwet discReference

Transmission TypeGearReference

forward and reverse options12 forward and reverseReference

Rear Axle Drive TypeplanetaryReference

PTO & Hydraulics

PTO (claimed)65.6 kWReference

Typeopen centerReference

Valves1 to 3Reference

SCV flow65.1 lpmReference

Rear TypeIIReference

Rear lift (at 24"/610mm)2199 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000 (1.375)Reference

Rear PTO Type540/540E (1.375)Reference

Dimensions

Wheelbase224 cmReference

Weight7478 to 8644 poundsReference

Front tire9.5L-15Reference

2WD Rear tire420/85R34Reference

2WD Standard tires (ag)Front: 9.5L-15. Rear: 420/85R34Reference

4WD Standard tires (ag)Front: 340/85R24. Rear: 420/85R34Reference

Flange rear axleReference

2WD ROPS3392 kgReference

4WD ROPS3508 kgReference

2WD Cab3762 kgReference

4WD Cab3920 kgReference

Massey Ferguson 4710 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps80Reference

Battery CCA590Reference

Battery volts12Reference

Total cold cranking amps590Reference

Attachment overview

AGCO 931X loaderReference

AGCO 936X loaderReference

General

Make & ModelMassey Ferguson (a part of AGCO)Reference

Rear Axle TypeFlangeReference

Country of manufacturerUtility tractorReference

Capacities

Capacity201 ciReference

Power

Rated Power100 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540/1,000 RPMReference

Steering & brakes

Brakeswet discReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves1 to 3Reference

Rear Hitch category (SAE designation)Category IIReference

Operator station

Cab AvailabilityAvailableReference

Cab Air conditioning, temperature differentialTwo-post folding ROPS. Cab optional with air-conditioning.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
