Massey Ferguson 4710M
Massey Ferguson 4710M — Utility tractor · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
8267 to 8708 pounds
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Utility tractorReference
Two- or four-wheel driveReference
Wet disc brakesReference
Cab standard.Reference
Engine
AGCO Power 3.3L 3-cyl dieselReference
Fuel tank124.9 LReference
Exhaust fluid (DEF)15.1 LReference
Engine74.6 kWReference
AGCO PowerReference
turbocharged dieselReference
3-cylinder 12-valveReference
liquid-cooled inlineReference
Displacement3.3 LReference
Bore/Stroke108 x 120 mmReference
EmissionsStage 5Reference
Power74.6 kWReference
Fuel systemcommon rail electronic injectionReference
Rated RPM2000Reference
Torque364.8 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
12-speed power shuttleReference
24-speed two-speed power shiftReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Six synchronized gears in two ranges with mechanical shuttle.Reference
Typepower shuttleReference
Six synchronized gears in two ranges with power shuttle.Reference
TransmissionDyna-2Reference
Typetwo-speed power shiftReference
Gears24 forward and reverseReference
Six gears in two ranges with two-speed power shift and power shuttle. Optional creeper range provides a total of 48 gear in each direction.Reference
PTO & Hydraulics
Pressure200.0 barReference
Pump flow65.1 lpmReference
Rear TypeIIReference
Rear lift3000 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1920Reference
Engine RPM540E@1560Reference
Engine RPM1000@1964Reference
Dimensions
Wheelbase225 cmReference
Weight8267 to 8708 poundsReference
Length406 cmReference
Width182 cmReference
Height (cab)255 cmReference
2WD Weight3749 kgReference
4WD Weight3949 kgReference
Ground clearance45 cmReference
Massey Ferguson 4710M attachments
front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
