Tractor · 2001Unverified

Massey Ferguson 475

Name: Massey Ferguson 475
Brand: Massey Ferguson

Massey Ferguson 475 — 400 Series · 110 hp. Reference specifications; pending source verification.

The Massey Ferguson 475 is a tractor with a rated power output of 110 hp, positioning it in the middle of its class for power. Manufactured between 2001 and 2010, the 475 features a 6-cylinder turbocharged diesel liquid-cooled engine, which drives through a mechanical front-wheel drive system with a hydrostatic transmission. The listed operating weights for the tractor range from 9083 to 9965 pounds. It is suitable for agricultural jobs that typically cover an area of around 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

110 hp

Max power

130 hp

Weight

9083 to 9965 pounds

Catalogue coverage

Variants represented

Richest spec table

84 rows

Recorded power

110 hp

Recorded weight

4120 kg

Transmissions

12-speed synchromesh

Production years

2001-2010

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Utility tractorReference

Built in Canoas, BrazilReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (optional)Reference

Steeringhydrostatic powerReference

Wet disc brakesReference

Open operator station. Two-post ROPS optional with available canopy.Reference

Engine

Perkins 6.0L 6-cyl dieselReference

Fuel tank210.1 LReference

Engine96.9 kWReference

Perkins 1006.6TReference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.0 LReference

Bore/Stroke100 x 127 mmReference

Power96.9 kWReference

Fuel systemdirect injectionReference

Rated RPM2200Reference

Torque510.1 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders6 cylinderReference

Rated engine speed2,200 RPMReference

Engine torque at rated speed170.6 kgReference

Bore and stroke3.937x5.00 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speed synchromeshReference

TypesynchromeshReference

Gears12 forward and 4 reverseReference

Transmission TypeSync ShuttleReference

forward and reverse optionsSynchromesh : 12F and 4RReference

Wheel Drive2 WD | 4 WD (Optional)Reference

PTO & Hydraulics

PTO (claimed)82.3 kWReference

Pressure170.0 barReference

Pump flow50.0 lpmReference

Rear TypeIIReference

Controldraft, position, and response controlReference

Rear PTOliveReference

Rear PTOindependent (optional)Reference

Rear PTO Type540 (1.375)Reference

Rear PTO Type540/1000 (optional)Reference

Engine RPM540@1900Reference

Dimensions

2WD Wheelbase271 cmReference

4WD Wheelbase273 cmReference

Weight9083 to 9965 poundsReference

Front tire9.00-16Reference

Rear tire18.4-34 (2WD)Reference

Standard tires (ag)Front: 9.00-16. Rear: 18.4-34 (2WD)Reference

Standard tires (ag)Front: 14.9-24. Rear: 18.4-34 (4WD)Reference

2WD Length455 cmReference

4WD Length463 cmReference

Height (ROPS)263 cmReference

Height (exhaust)279 cmReference

2WD Shipping weight4120 kgReference

4WD Shipping weight4520 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

General

Make & ModelMassey FergusonReference

Rollover protective structureTwo-post ROPS optional with available canopy.Reference

Country of manufacturerBrazilReference

Capacities

Capacity365.3 ciReference

Power

Max Power130 hpReference

PTO

PTO Power110.3 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Engine Speed on Rear PTO speed540@1,900 RPMReference

Steering & brakes

BrakesWet DiscReference

Steering typeHydrostatic PowerReference

Hydraulics

Pump Rated Output (total)13.2 gpmReference

Maximum operating pressure2,466 psiReference

Rear Hitch category (SAE designation)Category IIReference

Rear Hitch Sensing Typedraft, position, and response controlReference

Dimensions & weight

Wheelbase273.1 cmReference

Height Over ROPS263.9 cmReference

Overall Height279.9 cmReference

Overall Length463 cmReference

Overall weight4,520 kgReference

Wheels & tyres

Rear Wheel Type18.4-34 (2WD) | 18.4-34 (4WD)Reference

Front Wheel Type9.00-16.(2WD) | 14.9-24.(4WD)Reference

Operator station

Seat SuspensiontrueReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
