Tractor · 1983Unverified
Massey Ferguson 4780
Massey Ferguson 4780 — Four-wheel Drive (4WD) tractor · 215 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
215 hp
Weight
9348 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerMüllerReference
Four-wheel Drive (4WD) tractorReference
Built in BrazilReference
Four-wheel driveReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab standard with available heat and air-conditioning.Reference
Engine
Scania 11.0L 6-cyl dieselReference
Engine160.3 kWReference
Scania DN 1101-ML1Reference
dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement11.0 LReference
Bore/Stroke127 x 145 mmReference
Power160.3 kWReference
Fuel systemdirect injectionReference
Air cleanerdual dryReference
Compression16:1Reference
Rated RPM2200Reference
Torque774.8 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity25.0 LReference
Coolant capacity54.0 LReference
Transmission
10-speed constant meshReference
Typeconstant meshReference
Gears10 forward and 2 reverseReference
Clutch356mm cerametallic dry discReference
Capacities
Fuel559.8 LReference
PTO & Hydraulics
Hydraulic system99.9 LReference
Capacity99.9 LReference
Pressure143.2 barReference
Valves2Reference
Pump flow68.9 lpmReference
Rear TypeIIIReference
Rear lift5298 kgReference
Dimensions
Wheelbase299 cmReference
Weight9348 kgReference
Front tire18.4/15x34Reference
Standard tires (ag)Front: 18.4/15x34. Rear:Reference
Standard tires (ag)Front: 23.1/18x26. Rear:Reference
Optional tires (ag)Front: 18.4/15x34. Rear:Reference
Optional tires (ag)Front: 23.1/18x26. Rear:Reference
Ag front23.1/18x30Reference
Ag rear23.1/18x30Reference
Length586 cmReference
Width274 cmReference
Height343 cmReference
Shipping weight9348 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Battery AH165Reference
Speeds
With 23.1/18-30 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
