Lawn Tractor · 2015Unverified
Massey Ferguson 4900
Massey Ferguson 4900 — Front-mount mower · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
760 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerFerrisReference
Front-mount mowerReference
The Massey Ferguson 4900 is the same as the Ferris F800X.Reference
Two-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post folding ROPS.Reference
Engine
31HP Vanguard 896cc 2-cyl gasolineReference
Fuel tank45.4 LReference
Vanguard 543477Reference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement54.7 ciReference
Bore/Stroke86 x 78 mmReference
Power (gross)23.1 kWReference
Starter volts12Reference
Transmission
hydrostaticReference
ManufacturerParkerReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Hydro-Gear pumps with Parker wheel motors.Reference
Dimensions
Weight760 kgReference
Front tire13x6.50-6Reference
Rear tire24x12-12Reference
Lawn/turf front13x6.50-6Reference
Lawn/turf rear24x12-12Reference
Length293 cmReference
Height (ROPS)175 cmReference
Height (Folded ROPS)144 cmReference
Massey Ferguson 4900 attachments
72" front-mount mower deckReference
snowblowerReference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery CCA350Reference
Battery volts12Reference
Attachment overview
72" front-mount mower deckReference
SnowblowerReference
72" Mower deck
Typefront-mount FerrisReference
Type3-blade with electric liftReference
Cutting width182 cmReference
Overall width223 cmReference
Cut height3 to 12 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
