Industrial Tractor · Unverified
Massey Ferguson 50
Massey Ferguson 50 — ???? - 1970 Industrial tractor · 63 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Weight
2313 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Industrial tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Disc brakesReference
Open operator station.Reference
Engine
Perkins 3.3L 4-cyl dieselReference
Continental 3.2L 4-cyl gasolineReference
Engine47.0 kWReference
Perkins A4.203Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power44.0 kWReference
Fuel systemdirect injectionReference
Compression17.5:1Reference
Rated RPM2000Reference
Torque226.5 NmReference
Torque RPM1200Reference
Starter volts12Reference
Oil capacity7.1 LReference
ContinentalReference
gasolineReference
Displacement3.2 LReference
Bore/Stroke95 x 111 mmReference
Power47.0 kWReference
Fuel systemcarburetorReference
Compression7:1Reference
Torque238.7 NmReference
Oil capacity5.7 LReference
Transmission
6-speed mechanical shuttleReference
4-speed torque converterReference
Typemechanical shuttleReference
Gears6 forward and reverseReference
Typetorque converterReference
Gears4 forward and reverseReference
Capacities
Fuel64.3 LReference
PTO & Hydraulics
Hydraulic system22.7 LReference
Typeopen centerReference
Capacity22.7 LReference
Pressure137.9 barReference
Pump flow90.8 lpmReference
Dimensions
Wheelbase213 cmReference
Weight2313 kgReference
Front tire7.50-16Reference
Rear tire16.9-24Reference
Industrial front7.50-16Reference
Industrial rear16.9-24Reference
Width201 cmReference
Height (steering wheel)168 cmReference
Massey Ferguson 50 attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Gas Batteries1Reference
Diesel Batteries2Reference
Battery volts12Reference
Gas Battery AH95Reference
Diesel Battery AH60Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
