Tractor · 2002Unverified
Massey Ferguson 5275
Massey Ferguson 5275 — Utility tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
3030 kg
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Utility tractorReference
Built in Canoas, BrazilReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Perkins 4.1L 4-cyl dieselReference
Engine55.9 kWReference
Perkins 4.41Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke101 x 127 mmReference
Power55.9 kWReference
Air cleanerdual element dryReference
Rated RPM2200Reference
Torque261.0 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity9.5 LReference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Clutch305mm dry discReference
Capacities
Fuel99.9 LReference
PTO & Hydraulics
Hydraulic system37.9 LReference
Typeopen centerReference
Capacity37.9 LReference
Pressure150.0 barReference
Valves0 to 2Reference
Total flow42.0 lpmReference
Rear TypeIIReference
Controlposition and depth controlReference
Rear lift2100 kgReference
Rear lift2500 kgReference
Rear PTOtransmissionReference
Rear PTOliveReference
Rear PTOindependentReference
Clutch254mm dry discReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1900Reference
Dimensions
2WD Wheelbase213 cmReference
4WD Wheelbase211 cmReference
Weight3030 kgReference
Front tire7.50-16Reference
2WD Rear tire14.9-28Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 14.9-28Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9-30Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 18.4-30Reference
2WD Standard tires (ag)Front: 9.00-16. Rear: 23.1-26Reference
4WD Standard tires (ag)Front: 8.3-24. Rear: 14.9-28Reference
4WD Standard tires (ag)Front: 11.2-24. Rear: 16.9-30Reference
4WD Standard tires (ag)Front: 12.4-24. Rear: 18.4-30Reference
4WD Standard tires (ag)Front: 14.9-24. Rear: 23.1-26Reference
4WD Standard tires (ag)Front: 12.4-24. Rear: 13.6-36Reference
Length399 cmReference
Height264 cmReference
2WD Ground clearance36 cmReference
4WD Ground clearance34 cmReference
2WD Front tread130 to 210 cmReference
4WD Front tread164 to 203 cmReference
Rear tread155 to 216 cmReference
3030 kgReference
2WD Ballasted3652 kgReference
4WD Ballasted3800 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Battery AH90Reference
Speeds
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
