Tractor · 2002Unverified

Massey Ferguson 5285

Name: Massey Ferguson 5285
Brand: Massey Ferguson

Massey Ferguson 5285 — Utility tractor · 85 hp. Reference specifications; pending source verification.

The Massey Ferguson 5285 is a tractor with a rated output of 85 hp, placing it in the middle of its class in terms of power. It was manufactured from 2002 to 2009. The tractor features a 4-cylinder diesel liquid-cooled engine, coupled to a 12-speed gearbox, and four-wheel drive. Its listed weight ranges from 7495 to 7826 pounds, making it suitable for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

85 hp

Weight

7495 to 7826 pounds

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

85 hp

Recorded weight

3399 kg

Transmissions

12-speed

Production years

2002-2009

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

Built in Canoas, BrazilReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS.Reference

Engine

Perkins 4.1L 4-cyl dieselReference

Engine63.4 kWReference

Perkins 4.41Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.1 LReference

Bore/Stroke101 x 127 mmReference

Power63.4 kWReference

Air cleanerdual element dryReference

Rated RPM2200Reference

Torque288.0 NmReference

Torque RPM1200Reference

StarterelectricReference

Starter volts12Reference

Oil capacity9.5 LReference

Transmission

12-speedReference

Gears12 forward and 4 reverseReference

Clutch305mm dry discReference

Clutch330mm dry discReference

Capacities

Fuel99.9 LReference

PTO & Hydraulics

Hydraulic system37.9 LReference

Typeopen centerReference

Capacity37.9 LReference

Pressure150.0 barReference

Valves0 to 2Reference

Total flow42.0 lpmReference

Rear TypeIIReference

Controlposition and depth controlReference

Rear lift2100 kgReference

Rear lift2500 kgReference

Rear PTOtransmissionReference

Rear PTOliveReference

Rear PTOindependentReference

Clutch254mm dry discReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1900Reference

Dimensions

2WD Wheelbase213 cmReference

4WD Wheelbase211 cmReference

Weight7495 to 7826 poundsReference

Length399 cmReference

Height264 cmReference

2WD Weight3399 kgReference

4WD Weight3549 kgReference

2WD Ground clearance36 cmReference

4WD Ground clearance34 cmReference

2WD Front tread130 to 210 cmReference

4WD Front tread164 to 203 cmReference

Rear tread155 to 216 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps35Reference

Battery volts12Reference

Battery AH90Reference

Speeds

With 18.4-34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
