Tractor · 2008Unverified
Massey Ferguson 5425
Massey Ferguson 5425 — Utility tractor · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Max power
60.5 kW
Weight
9198 to 9848 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in Beauvais, FranceReference
Original price$38,042 (2009 ROPS 2WD )Reference
Original price$56,602 (2009 Cab 4WD )Reference
During official testing, the Massey 5425 optional open-center hydraulic pump was unable to produce 26 GPM, actual delivery was 24.1 GPM.Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank143.8 LReference
Fuel tank189.2 LReference
Engine (gross)59.7 kWReference
Drawbar (tested)47.7 kWReference
Perkins 1104Reference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier IIIReference
Power (gross)59.7 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression18.2:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Max power60.5 kWReference
Power at rated engine speed57.2 kWReference
Max power47.7 kWReference
Transmission
16-speed partial power shiftReference
TransmissionDyna-4Reference
Typepartial power shiftReference
Gears16 forward and reverseReference
Clutchwet discReference
Four power shift gears in four ranges.Reference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
PTO (tested)60.5 kWReference
Typeopen centerReference
Valves2 to 4Reference
Pump flow56.8 lpmReference
Pump flow98.4 lpmReference
Rear TypeIIReference
Controlelectronic draft controlReference
Rear lift (at 24"/610mm)3545 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed60.5 kWReference
Dimensions
Wheelbase255 cmReference
Wheelbase246 cmReference
Weight9198 to 9848 poundsReference
Front tire9.5L-15Reference
2WD Rear tire420/85R30Reference
2WD Standard tires (ag)Front: 9.5L-15. Rear: 420/85R30Reference
4WD Standard tires (ag)Front: 340/85R24. Rear: 420/85R34Reference
2WD Optional tires (ag)Front: 9.5L-15. Rear: 420/85R34Reference
2WD Optional tires (ag)Front: 9.5L-15. Rear: 460/85R30Reference
2WD Optional tires (ag)Front: 10.00-16. Rear: 420/85R34Reference
2WD Optional tires (ag)Front: 10.00-16. Rear: 460/85R34Reference
2WD Optional tires (ag)Front: 10.00-16. Rear: 460/85R30Reference
2WD Optional tires (ag)Front: 11.00-16. Rear: 460/85R34Reference
2WD Optional tires (ag)Front: 10.00-16. Rear: 380/80R38Reference
2WD Optional tires (ag)Front: 10.00-16. Rear: 420/85R38Reference
2WD Optional tires (ag)Front: 11.00-16. Rear: 420/85R38Reference
2WD Optional tires (ag)Front: 11.00-16. Rear: 460/85R38Reference
4WD Optional tires (ag)Front: 380/85R24. Rear: 460/85R34Reference
4WD Optional tires (ag)Front: 280/85R24. Rear: 420/85R30Reference
4WD Optional tires (ag)Front: 320/85R24. Rear: 460/85R30Reference
4WD Optional tires (ag)Front: 380/70R24. Rear: 480/70R34Reference
4WD Optional tires (ag)Front: 340/85R24. Rear: 380/80R38Reference
4WD Optional tires (ag)Front: 340/85R28. Rear: 420/85R38Reference
4WD Optional tires (ag)Front: 380/70R28. Rear: 480/70R38Reference
4WD Optional tires (ag)Front: 380/85R28. Rear: 460/85R38Reference
Length420 cmReference
Width201 cmReference
Width255 cmReference
Height (cab)275 cmReference
Shipping weight4172 kgReference
Shipping weight4467 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps80Reference
Battery CCA775Reference
Battery volts12Reference
Test results
Diesel 16-speed 4WDJune 2009 - 2009, Link: OCED Tractor Test 2532 fileReference
PTO performanceReference
Fuel use18.2 l/hourReference
Fuel use18.5 l/hourReference
Drawbar performanceReference
Gear 3A used for power test.Reference
Max pull3631 kgReference
Gear 1D used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
