Tractor · 2006Unverified
Massey Ferguson 543
Massey Ferguson 543 — 500 Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
4962 to 5456 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in BrazilReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Final drivesplanetaryReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Perkins 3.3L 3-cyl dieselReference
Fuel tank48.1 LReference
Engine38.8 kWReference
Perkins 1103C-33Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke105 x 127 mmReference
Power38.8 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
8-speedReference
TransmissiongearReference
Gears8 forward and 2 reverseReference
Clutch305mm dry discReference
TransmissionshuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)33.6 kWReference
Typeopen centerReference
Valves2Reference
Pump flow50.7 lpmReference
Total flow71.5 lpmReference
Rear TypeI/IIReference
Rear lift (at 24"/610mm)1229 kgReference
Rear PTOliveReference
Rear PTOindependent (optional)Reference
Rear PTO Type540Reference
Dimensions
Wheelbase194 cmReference
Weight4962 to 5456 poundsReference
Length322 cmReference
Width169 cmReference
Height234 cmReference
Shipping weight2250 kgReference
Shipping weight2474 kgReference
Ground clearance33 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
