Industrial Tractor · Unverified

Massey Ferguson 55

Name: Massey Ferguson 55
Brand: Massey Ferguson

Massey Ferguson 55 — Wheel Loader · 138 hp. Reference specifications; pending source verification.

The Massey Ferguson 55 is a high-powered industrial tractor, rated at 138 hp. It is equipped with an 8-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system using a powershift transmission. The tractor's weight is listed as 25745 to 26260 pounds. It is designed for use in areas of around 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

138 hp

Weight

25745 to 26260 pounds

Catalogue coverage

Variants represented

Richest spec table

57 rows

Recorded power

138 hp

Recorded weight

11677 kg

Transmissions

4-speed power shift

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Wheel LoaderReference

Four-wheel driveReference

Articulated power steeringReference

Pneumatic-hydraulic drum brakesReference

Open operator station. Four-post ROPS available.Reference

Engine

Perkins 8.4L 8-cyl dieselReference

Engine (net)102.9 kWReference

Perkins AV8.510Reference

dieselReference

8-cylinderReference

liquid-cooledReference

Displacement8.4 LReference

Bore/Stroke108 x 114 mmReference

Power (net)102.9 kWReference

Air cleanerdryReference

Rated RPM2250Reference

Torque519.3 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Oil capacity17.0 LReference

Coolant capacity55.6 LReference

Transmission

4-speed power shiftReference

Typepower shiftReference

Gears4 forward and reverseReference

Capacities

Fuel276.3 LReference

PTO & Hydraulics

Hydraulic system170.3 LReference

Typeopen centerReference

Capacity170.3 LReference

Pressure137.9 barReference

Pump flow132.5 lpmReference

Dimensions

Wheelbase279 cmReference

Weight25745 to 26260 poundsReference

Front tire20.5-25Reference

Rear tire20.5-25Reference

Industrial front20.5-25Reference

Industrial rear20.5-25Reference

Industrial front16.00x24Reference

Industrial front17.5x25Reference

Industrial rear16.00x24Reference

Industrial rear17.5x25Reference

Length668 cmReference

Width243 cmReference

Height (steering wheel)251 cmReference

Height (cab)340 cmReference

Shipping weight11677 kgReference

Operating weight11911 kgReference

Ground clearance41 cmReference

Front tread198 cmReference

Rear tread198 cmReference

Massey Ferguson 55 attachments

front-end loaderReference

Electrical

Charging systemalternatorReference

Charging amps42Reference

Batteries2Reference

Battery volts12Reference

Battery AH170Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
