Industrial Tractor · Unverified
Massey Ferguson 55
Massey Ferguson 55 — Wheel Loader · 138 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
138 hp
Weight
25745 to 26260 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Wheel LoaderReference
Four-wheel driveReference
Articulated power steeringReference
Pneumatic-hydraulic drum brakesReference
Open operator station. Four-post ROPS available.Reference
Engine
Perkins 8.4L 8-cyl dieselReference
Engine (net)102.9 kWReference
Perkins AV8.510Reference
dieselReference
8-cylinderReference
liquid-cooledReference
Displacement8.4 LReference
Bore/Stroke108 x 114 mmReference
Power (net)102.9 kWReference
Air cleanerdryReference
Rated RPM2250Reference
Torque519.3 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity17.0 LReference
Coolant capacity55.6 LReference
Transmission
4-speed power shiftReference
Typepower shiftReference
Gears4 forward and reverseReference
Capacities
Fuel276.3 LReference
PTO & Hydraulics
Hydraulic system170.3 LReference
Typeopen centerReference
Capacity170.3 LReference
Pressure137.9 barReference
Pump flow132.5 lpmReference
Dimensions
Wheelbase279 cmReference
Weight25745 to 26260 poundsReference
Front tire20.5-25Reference
Rear tire20.5-25Reference
Industrial front20.5-25Reference
Industrial rear20.5-25Reference
Industrial front16.00x24Reference
Industrial front17.5x25Reference
Industrial rear16.00x24Reference
Industrial rear17.5x25Reference
Length668 cmReference
Width243 cmReference
Height (steering wheel)251 cmReference
Height (cab)340 cmReference
Shipping weight11677 kgReference
Operating weight11911 kgReference
Ground clearance41 cmReference
Front tread198 cmReference
Rear tread198 cmReference
Massey Ferguson 55 attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Charging amps42Reference
Batteries2Reference
Battery volts12Reference
Battery AH170Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
