Massey Ferguson 5709S
Massey Ferguson 5709S — Utility tractor · 95 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
95 hp
Weight
4799 kg
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Utility tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakespneumaticReference
Trailer brakeshydraulicReference
Cab standard with air-conditioning.Reference
Variants
5709MbasicReference
5709SdeluxeReference
Engine
AGCO Power 4.4L 4-cyl dieselReference
Fuel tank180.2 LReference
Exhaust fluid (DEF)25.0 LReference
Engine67.1 kWReference
Engine (max)70.8 kWReference
AGCO PowerReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
EmissionsTier IVReference
Power67.1 kWReference
Maximum Power70.8 kWReference
Rated RPM2200Reference
Torque405.4 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed four-speed power shiftReference
24-speed six-speed power shiftReference
TransmissionDyna-4Reference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
Four power shift speeds in four ranges with power shuttle.Reference
TransmissionDyna-6Reference
Typesix-speed power shiftReference
Gears24 forward and reverseReference
Six power shift speeds in four ranges with power shuttle.Reference
PTO & Hydraulics
Typeopen centerReference
Typeclosed centerReference
Pressure200.0 barReference
Valves2 to 4Reference
Pump flow57.9 lpmReference
Pump flow99.9 lpmReference
Pump flow109.8 lpmReference
Steering flow32.2 lpmReference
Rear TypeIII/IIReference
Rear lift5200 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1920Reference
Engine RPM540E@1560Reference
Engine RPM1000@1960Reference
Dimensions
Wheelbase255 cmReference
Weight4799 kgReference
Length435 cmReference
Width201 cmReference
Height (cab)277 cmReference
Max weight8500 kgReference
Ground clearance40 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
