Tractor · 2020Unverified
Massey Ferguson 5710M
Massey Ferguson 5710M — Utility tractor · 105 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
105 hp
Weight
8973 to 9700 pounds
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Cab standard with available air-conditioning.Reference
Variants
5710MbasicReference
5710SdeluxeReference
Engine
AGCO Power 4.4L 4-cyl dieselReference
Power shuttle Fuel tank152.9 LReference
Dyna-4 Fuel tank160.1 LReference
Exhaust fluid (DEF)18.2 LReference
Engine74.6 kWReference
Engine (max)78.3 kWReference
Power shuttle Weight4070 kgReference
AGCO PowerReference
turbocharged intercooled dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
EmissionsTier IVReference
Power74.6 kWReference
Maximum Power78.3 kWReference
Rated RPM2200Reference
Torque440.7 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed power shuttleReference
16-speed four-speed power shiftReference
Typepower shuttleReference
Gears12 forward and reverseReference
Six synchronized gears in two ranges with power shuttle.Reference
TransmissionDyna-4Reference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
Four power shift speeds in four ranges with power shuttle.Reference
PTO & Hydraulics
Typeopen centerReference
Pressure200.0 barReference
Valves2 or 3Reference
Pump flow57.9 lpmReference
Pump flow99.9 lpmReference
Steering flow32.9 lpmReference
Rear TypeIIReference
Rear lift4300 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2000Reference
Engine RPM540E@1550Reference
Engine RPM1000@2000Reference
Dimensions
Wheelbase243 cmReference
Weight8973 to 9700 poundsReference
Length430 cmReference
Width179 cmReference
Height (cab)268 cmReference
Dyna-4 Weight4399 kgReference
Ground clearance51 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
