Tractor · 2017Unverified

Massey Ferguson 5711

Name: Massey Ferguson 5711
Brand: Massey Ferguson

Massey Ferguson 5711 — Utility tractor · 110 hp. Reference specifications; pending source verification.

The Massey Ferguson 5711 is a 110 hp tractor, situated in the middle of its class for power output. Manufactured between 2017 and 2021, this model is equipped with a 4-cylinder, turbocharged, intercooled diesel liquid-cooled engine. It features four-wheel drive with a powershift transmission and a listed weight of 9195 to 10011 pounds. This tractor is designed for use in areas of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

110 hp

Weight

9195 to 10011 pounds

Catalogue coverage

Variants represented

Richest spec table

66 rows

Recorded power

110 hp

Recorded weight

4170 kg

Transmissions

12-speed mechanical shuttle

Production years

2017-2021

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

Original price was $65,553 in 2019Reference

Four-wheel driveReference

Final drivesinternal planetaryReference

Differential lockelectro-hydraulic rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional.Reference

Engine

AGCO Power 4.4L 4-cyl dieselReference

Fuel tank145.0 LReference

Engine78.3 kWReference

Engine (max)82.0 kWReference

AGCO PowerReference

intercooled turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke108 x 120 mmReference

EmissionsTier IVReference

Emission controlselective catalytic reduction (SCR)Reference

Power78.3 kWReference

Maximum Power82.0 kWReference

Fuel systemhigh-pressure common rail direct injectionReference

Rated RPM2200Reference

Torque565.5 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed mechanical shuttleReference

12-speed power shuttleReference

16-speed four-speed power shiftReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

Typepower shuttleReference

Clutchwet discReference

TransmissionDyna-4Reference

Typefour-speed power shiftReference

Gears16 forward and reverseReference

PTO & Hydraulics

PTO (claimed)69.4 kWReference

PTO (claimed)71.6 kWReference

Typeopen centerReference

Valves2 or 3Reference

Pump flow57.2 lpmReference

Pump flow98.0 lpmReference

Rear TypeIIReference

Rear lift (at 24"/610mm)3497 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Rear PTO Type540/540E/1000Reference

Dimensions

Wheelbase243 cmReference

Weight9195 to 10011 poundsReference

Width179 cmReference

ROPS Weight4170 kgReference

Cab Weight4540 kgReference

Flange rear axleReference

Massey Ferguson 5711 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps80Reference

Battery volts12Reference

Attachment overview

Massey Ferguson 941X loaderReference

Massey Ferguson 946X loaderReference

Massey Ferguson FL3723 loaderReference

Massey Ferguson FL3819 loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
