Tractor · 2020Unverified

Massey Ferguson 5712M

Name: Massey Ferguson 5712M
Brand: Massey Ferguson

Massey Ferguson 5712M — Utility tractor · 125 hp. Reference specifications; pending source verification.

The Massey Ferguson 5712M is a tractor with a rated power of 125 hp, placing it at the powerful end of its class. The 5712M was manufactured from 2020 to 2024. Key features include a 4-cylinder turbocharged intercooled diesel liquid-cooled engine and four-wheel drive, paired with a 12-speed gearbox. Its listed operating weight is 4230 kg, suitable for operations spanning 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

125 hp

Weight

4230 kg

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

125 hp

Recorded weight

4230 kg

Transmissions

12-speed power shuttle

Production years

2020-2024

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

Four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Trailer brakespneumaticReference

Cab standard with available air-conditioning.Reference

Variants

5712MbasicReference

5712SdeluxeReference

Engine

AGCO Power 4.4L 4-cyl dieselReference

Fuel tank152.9 LReference

Exhaust fluid (DEF)18.2 LReference

Engine89.5 kWReference

Engine (max)93.2 kWReference

AGCO PowerReference

turbocharged intercooled dieselReference

4-cylinder 16-valveReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke108 x 120 mmReference

EmissionsTier IVReference

Power89.5 kWReference

Maximum Power93.2 kWReference

Rated RPM2200Reference

Torque520.7 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed power shuttleReference

Typepower shuttleReference

Gears12 forward and reverseReference

Six synchronized gears in two ranges with power shuttle.Reference

PTO & Hydraulics

Typeopen centerReference

Pressure200.0 barReference

Valves2 or 3Reference

Pump flow57.9 lpmReference

Pump flow99.9 lpmReference

Steering flow32.9 lpmReference

Rear TypeIIIReference

Rear lift5200 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2000Reference

Engine RPM540E@1550Reference

Engine RPM1000@2000Reference

Dimensions

Wheelbase249 cmReference

Weight4230 kgReference

Length430 cmReference

Width179 cmReference

Height (cab)273 cmReference

Ground clearance52 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
