Massey Ferguson 5713M
Massey Ferguson 5713M — Utility tractor · 135 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
135 hp
Weight
4230 kg
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Cab standard with available air-conditioning.Reference
Variants
5713MbasicReference
5713SdeluxeReference
Engine
AGCO Power 4.4L 4-cyl dieselReference
Fuel tank152.9 LReference
Exhaust fluid (DEF)18.2 LReference
Engine96.9 kWReference
Engine (max)100.7 kWReference
AGCO PowerReference
turbocharged intercooled dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
EmissionsTier IVReference
Power96.9 kWReference
Maximum Power100.7 kWReference
Rated RPM2200Reference
Torque545.1 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed power shuttleReference
Typepower shuttleReference
Gears12 forward and reverseReference
Six synchronized gears in two ranges with power shuttle.Reference
PTO & Hydraulics
Typeopen centerReference
Pressure200.0 barReference
Valves2 or 3Reference
Pump flow57.9 lpmReference
Pump flow99.9 lpmReference
Steering flow32.9 lpmReference
Rear TypeIIIReference
Rear lift5200 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2000Reference
Engine RPM540E@1550Reference
Engine RPM1000@2000Reference
Dimensions
Wheelbase249 cmReference
Weight4230 kgReference
Length430 cmReference
Width179 cmReference
Height (cab)273 cmReference
Ground clearance52 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
