Tractor · 2006Unverified

Massey Ferguson 573

Name: Massey Ferguson 573
Brand: Massey Ferguson

Massey Ferguson 573 — 500 Series · 72 hp. Reference specifications; pending source verification.

The Massey Ferguson 573 is a tractor with a rated output of 72 hp, a power level typical of its class. It was manufactured from 2006 to 2010. The tractor features a 4-cylinder diesel liquid-cooled engine, coupled with a mechanical front-wheel drive system and hydrostatic transmission. Its listed operating weight ranges from 5578 to 7319 pounds, making it suitable for tasks covering areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

72 hp

Max power

49.4 kW

Weight

5578 to 7319 pounds

Catalogue coverage

Variants represented

Richest spec table

106 rows

Recorded power

72 hp

Transmissions

8-speed

Production years

2006-2010

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Utility tractorReference

Built in BrazilReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD optionalReference

Steeringhydrostatic powerReference

Independent hydraulic wet disc brakesReference

Two-post foldable ROPS. Cab optional with air-condtioning.Reference

Variants

573LPlow-profileReference

Engine

Perkins 4.4L 4-cyl dieselReference

ROPS Fuel tank99.9 LReference

Cab Fuel tank104.8 LReference

Engine (gross)53.7 kWReference

Perkins 1104C-44Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

Power (gross)53.7 kWReference

Air cleanerdual paper elementsReference

Compression19.3:1Reference

Rated RPM2200Reference

Starter volts12Reference

Max power49.4 kWReference

Power at rated engine speed47.9 kWReference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,200 RPMReference

Bore and stroke4.134x5.00 inchesReference

Compression ratio19.3:1Reference

Cooling systemliquid-cooledReference

Transmission

8-speedReference

12-speedReference

TransmissiongearReference

Gears8 forward and 2 reverseReference

Clutch305mm dry discReference

TransmissionshuttleReference

Gears8 forward and reverseReference

Transmissionpartial synchReference

Gears12 forward and 4 reverseReference

Transmission TypeGearReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)44.7 kWReference

PTO (tested)49.4 kWReference

Typeopen centerReference

Valves2 or 3Reference

Pump flow54.9 lpmReference

Total flow85.2 lpmReference

Rear TypeIIReference

Rear lift (at 24"/610mm)1790 kgReference

Rear PTOliveReference

Rear PTOindependent (optional, standard with cab)Reference

Rear PTO Type540Reference

Power at rated PTO speed47.9 kWReference

Dimensions

Wheelbase229 cmReference

Weight5578 to 7319 poundsReference

Front tire9.5L-15Reference

Rear tire16.9-30Reference

Ag front9.5L-15Reference

Ag rear16.9-30Reference

Length358 cmReference

Length350 cmReference

Length358 cmReference

Length343 cmReference

Width200 cmReference

Width199 cmReference

Ground clearance37 cmReference

Ground clearance27 cmReference

Shipping2530 kgReference

Shipping2859 kgReference

Shipping2990 kgReference

Shipping3319 kgReference

Operating2726 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Massey Ferguson 573 Height

260 cmReference

266 cmReference

248 cmReference

Test results

Diesel 8-speed shuttle 2WDOctober 31 - November 3, 2005Link: Nebraska Tractor Test 1864 fileReference

PTO performanceReference

Fuel use16.3 l/hourReference

Fuel use15.5 l/hourReference

General

Make & ModelMassey FergusonReference

Rollover protective structureTwo-post foldable ROPS.Reference

Country of manufacturerBrazilReference

Capacities

Capacity268.6 ciReference

Fuel tank104.9 LReference

PTO

PTO Power60 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Steering & brakes

Brakesindependent hydraulic wet discReference

Steering typehydrostatic powerReference

Hydraulics

Pump Rated Output (total)22.5 gpmReference

Hydraulics Typeopen centerReference

Remote Valves2 or 3 ValvesReference

Rear Hitch category (SAE designation)Category IIReference

Dimensions & weight

Height Over Cab267 cmReference

Height Over ROPS260.1 cmReference

Overall Length358.9 cmReference

Overall Width200.9 cmReference

Overall weight2,859.9 kgReference

Wheels & tyres

Rear Wheel Type16.9-30Reference

Front Wheel Type9.5L-15Reference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
