Tractor · 2006Unverified
Massey Ferguson 583
Massey Ferguson 583 — 500 Series · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
5578 to 7319 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in BrazilReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-condtioning.Reference
Variants
583LPlow-profileReference
Engine
Perkins 4.4L 4-cyl dieselReference
ROPS Fuel tank99.9 LReference
Cab Fuel tank104.8 LReference
Engine (gross)59.7 kWReference
Perkins 1104C-44Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
Power (gross)59.7 kWReference
Compression18.2:1Reference
Rated RPM2200Reference
Starter volts12Reference
Power at rated engine speed54.9 kWReference
Transmission
8-speedReference
12-speedReference
TransmissiongearReference
Gears8 forward and 2 reverseReference
Clutch305mm dry discReference
TransmissionshuttleReference
Gears8 forward and reverseReference
Transmissionpartial synchReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)52.2 kWReference
PTO (tested)54.9 kWReference
Typeopen centerReference
Valves2 or 3Reference
Pump flow54.9 lpmReference
Total flow85.2 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1790 kgReference
Rear PTOliveReference
Rear PTOindependent (optional, standard with cab)Reference
Rear PTO Type540Reference
Power at rated PTO speed50.0 kWReference
Dimensions
Wheelbase229 cmReference
Weight5578 to 7319 poundsReference
Front tire9.5L-15Reference
Rear tire16.9-30Reference
Ag front9.5L-15Reference
Ag rear16.9-30Reference
Length358 cmReference
Length350 cmReference
Length358 cmReference
Length343 cmReference
Width200 cmReference
Width199 cmReference
Ground clearance37 cmReference
Ground clearance27 cmReference
2WD ROPS Shipping2530 kgReference
4WD ROPS Shipping2859 kgReference
2WD cab Shipping2990 kgReference
4WD cab Shipping3319 kgReference
2WD ROPS Operating2721 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Massey Ferguson 583 Height
260 cmReference
266 cmReference
248 cmReference
Test results
Diesel 8-speed shuttle 2WDNovember 1 - 3, 2005Link: Nebraska Tractor Test 1865 fileReference
PTO performanceReference
Fuel use18.5 l/hourReference
Fuel use16.3 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
