Backhoe Loader · 1986Unverified
Massey Ferguson 60H
Massey Ferguson 60H — Backhoe loader tractor · 77 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
77 hp
Weight
13671 to 14103 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Backhoe loader tractorReference
Two- or four-wheel driveReference
Final drivesoutboard planetaryReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with heater. Four-post ROPS/FOPS available.Reference
Engine
Perkins 4.1L 4-cyl dieselReference
Engine (gross)57.4 kWReference
Perkins A4.248Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke101 x 127 mmReference
Power (gross)57.4 kWReference
Air cleanerdual dry elementReference
Pre-heatingthermostartReference
Compression16:1Reference
Rated RPM2000Reference
Torque286.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity9.4 LReference
Coolant capacity15.8 LReference
Transmission
4-speed power shuttleReference
Typepower shuttleReference
Gears4 forward and reverseReference
Oil capacity49.0 LReference
Capacities
Fuel81.0 LReference
PTO & Hydraulics
Hydraulic system71.9 LReference
Typeopen centerReference
Capacity71.9 LReference
Pressure189.6 barReference
Pump flow124.9 lpmReference
Dimensions
2WD Wheelbase218 cmReference
4WD Wheelbase217 cmReference
Weight13671 to 14103 poundsReference
Front tire11L-16Reference
Rear tire16.9-28Reference
2WD Industrial front11L-16Reference
4WD Industrial front12/12.5-18Reference
Industrial rear16.9-28Reference
Industrial front14-17.5Reference
Industrial rear19.5L-24Reference
Length778 cmReference
Width223 cmReference
2WD Weight6201 kgReference
4WD Weight6397 kgReference
Ground clearance34 cmReference
2WD Front tread167 cmReference
4WD Front tread180 cmReference
Rear tread173 cmReference
Steering wheel207 cmReference
Backhoe & Loader
Dump angle127 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Batteries2Reference
Battery CCA340Reference
Battery volts12Reference
Battery AH125Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Massey Ferguson 475 Backhoe
Backhoe typeMassey Ferguson 475 BackhoeReference
Transport height387 cmReference
2-Foot flat digging depth474 cmReference
Reach from pivot598 cmReference
Loading height417 cmReference
Bucket Rotation194°Reference
Bucket force4878 kgReference
Dipperstick force3449 kgReference
Massey Ferguson 475 Extendible Backhoe
Backhoe typeMassey Ferguson 475 Extendible BackhoeReference
Transport height387 cmReference
2-Foot flat digging depth (extended stick)609 cmReference
Reach from pivot (extended stick)727 cmReference
Loading height (extended stick)513 cmReference
Bucket Rotation194°Reference
Bucket force4878 kgReference
Dipperstick force3449 kgReference
Massey Ferguson 60H Height
ROPS272 cmReference
Cab277 cmReference
Exhaust266 cmReference
Backhoe387 cmReference
Speeds
With 16.9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
