Tractor · 1999Unverified

Massey Ferguson 6245

Name: Massey Ferguson 6245
Brand: Massey Ferguson

Massey Ferguson 6245 — Row-Crop tractor · 76 hp. Reference specifications; pending source verification.

The Massey Ferguson 6245 is a tractor with a rated output of 76 hp, placing it in the middle of its class in terms of power. Production of this model took place from 1999 to 2003. The tractor is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine and features four-wheel drive with a hydrostatic transmission. Its listed weight is 4229 kg, and it is suitable for tasks of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

76 hp

Max power

60.0 kW

Weight

4229 kg

Catalogue coverage

Variants represented

Richest spec table

62 rows

Recorded power

76 hp

Recorded weight

4229 kg

Transmissions

32-speed four-speed power shift

Production years

1999-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Row-Crop tractorReference

Built in Beauvais, FranceReference

Original price$60,000Reference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Independent hydraulic wet discs brakesReference

Cab standard. Two-post ROPS platform available. Fieldstar optionalReference

Engine

Perkins 4.0L 4-cyl dieselReference

Drawbar (tested)50.7 kWReference

PerkinsReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.0 LReference

Bore/Stroke100 x 127 mmReference

Air cleanerdual paper elementsReference

Compression17.3:1Reference

Rated RPM2200Reference

Starter volts12Reference

Max power60.0 kWReference

Power at rated engine speed56.4 kWReference

Max power50.7 kWReference

Transmission

32-speed four-speed power shiftReference

TransmissionDynashiftReference

Typefour-speed power shiftReference

Gears32 forward and reverseReference

Clutchwet discReference

Four power shift ranges (A-D) in four gears (1-4) with two ranges (low/high).Reference

TransmissionDynaShuttleReference

Optional DynaShuttle transmission adds a left-hand multifunction control lever for shuttle, power shift, and clutch control. Four power shift ranges (A-D) in four gears (1-4) with two ranges (low/high).Reference

PTO & Hydraulics

PTO (claimed)55.9 kWReference

PTO (tested)60.0 kWReference

Hydraulic system68.1 LReference

Typeopen centerReference

Typeclosed center pressure flow compensated optionalReference

Capacity68.1 LReference

Valves2Reference

Pump flow56.4 lpmReference

Rear TypeIIReference

Rear lift3175 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Power at rated PTO speed59.3 kWReference

Capacities

Fuel132.5 LReference

Dimensions

Wheelbase246 cmReference

Weight4229 kgReference

Front tire13.6R-24Reference

Rear tire16.9R-34Reference

Ag front13.6R-24Reference

Ag rear16.9R-34Reference

Operating weight4229 kgReference

Electrical

GroundnegativeReference

Test results

Diesel 32-speed 4WDApril 1, 1998 - June 1, 1999Link: OCED Tractor Test 1851 fileReference

PTO performanceReference

Fuel use18.5 l/hourReference

Fuel use18.9 l/hourReference

Fuel use18.2 l/hourReference

Drawbar performanceReference

Gear 17 used for power test.Reference

Max pull3578 kgReference

Gear 7 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
