Tractor · 1999Unverified
Massey Ferguson 6290
Massey Ferguson 6290 — Row-Crop tractor · 121 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
121 hp
Max power
84.7 kW
Weight
10625 to 11565 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Row-Crop tractorReference
Built in Beauvais, FranceReference
Original price$57,400Reference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Independent hydraulic wet disc brakesReference
Cab standard. Two-post ROPS platform available. Fieldstar optionalReference
Engine
Perkins 6.0L 6-cyl dieselReference
Drawbar (tested)84.7 kWReference
PerkinsReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.0 LReference
Bore/Stroke100 x 127 mmReference
Air cleanerdual paper elementsReference
Compression16.0:1Reference
Rated RPM2200Reference
Starter volts12Reference
Coolant capacity25.0 LReference
Power at rated engine speed89.9 kWReference
Max power84.7 kWReference
Transmission
32-speed four-speed power shiftReference
TransmissionDynashiftReference
Typefour-speed power shiftReference
Gears32 forward and reverseReference
Clutchwet discReference
Four power shift ranges (A-D) in four gears (1-4) with two ranges (low/high).Reference
TransmissionDynaShuttleReference
Optional DynaShuttle transmission adds a left-hand multifunction control lever for shuttle, power shift, and clutch control. Four power shift ranges (A-D) in four gears (1-4) with two ranges (low/high).Reference
PTO & Hydraulics
PTO (claimed)89.5 kWReference
PTO (tested)89.9 kWReference
Hydraulic system62.1 LReference
Typeopen centerReference
Typeclosed center pressure flow compensated optionalReference
Capacity62.1 LReference
Valves2Reference
Pump flow56.4 lpmReference
Rear TypeIIReference
Rear lift4173 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed94.1 kWReference
Capacities
Fuel223.3 LReference
Dimensions
Wheelbase270 cmReference
Weight10625 to 11565 poundsReference
Front tire10.00-16Reference
Rear tire16.9R-38Reference
Ag front10.00-16Reference
Ag rear16.9R-38Reference
Length469 cmReference
Height (cab)310 cmReference
2WD Operating weight4819 kgReference
4WD Operating weight5245 kgReference
Massey Ferguson 6290 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Test results
Diesel 32-speed 4WDOctober 1 - November 1, 1999Link: OCED Tractor Test 1874 fileReference
PTO performanceReference
Fuel use28.0 l/hourReference
Fuel use27.3 l/hourReference
Drawbar performanceReference
Fuel use29.1 l/hourReference
Gear 13 used for power test.Reference
Max pull4955 kgReference
Gear 11 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
