Tractor · 2003Unverified

Massey Ferguson 660

Name: Massey Ferguson 660
Brand: Massey Ferguson

Massey Ferguson 660 — 600 Series · 74 hp. Reference specifications; pending source verification.

The Massey Ferguson 660 is a tractor model with an approximate power output of 74 hp, a mid-range rating for its class. It was manufactured between 2003 and 2009. The tractor is equipped with a 6-cylinder, turbocharged diesel engine, and features four-wheel drive with a 12-speed gearbox. Its operating weight is listed as 13228 to 14054 pounds, with a suitability for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

74 hp

Weight

13228 to 14054 pounds

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

74 hp

Recorded weight

6000 kg

Transmissions

12-speed synchronized

Production years

2003-2009

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Row-Crop tractorReference

Two- or four-wheel driveReference

Differential lockmechanical rearReference

Two-post ROPS. Cab optional.Reference

Engine

Perkins 6.0L 6-cyl dieselReference

Fuel tank445.1 LReference

Engine111.9 kWReference

Perkins 1006.6TReference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.0 LReference

Bore/Stroke100 x 127 mmReference

EmissionsTier 0Reference

Power111.9 kWReference

Rated RPM2200Reference

Torque554.6 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchronizedReference

TypesynchronizedReference

Gears12 forward and 5 reverseReference

Clutch330mm cerametallic discsReference

PTO & Hydraulics

PTO (claimed)54.8 kWReference

Pressure210.0 barReference

Pump flow60.2 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift4500 kgReference

Rear lift5499 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2160Reference

Engine RPM1000@2160Reference

Dimensions

Wheelbase294 cmReference

Weight13228 to 14054 poundsReference

Front tire14.9-28Reference

Rear tire18.4-38Reference

Standard tires (ag)Front: 14.9-28. Rear: 18.4-38Reference

Length485 cmReference

Height (ROPS)294 cmReference

Height (cab)297 cmReference

ROPS Weight6000 kgReference

Cab Weight6374 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
