Tractor · 2014Unverified

Massey Ferguson 6616

Name: Massey Ferguson 6616
Brand: Massey Ferguson

Massey Ferguson 6616 — Utility tractor · 120 hp. Reference specifications; pending source verification.

The Massey Ferguson 6616 is a tractor rated at approximately 120 hp, placing it at the upper end of its class in terms of power. It was manufactured from 2014 to 2016. The 6616 is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a continuously variable transmission. Its listed operating weight is 5670 kg, making it suitable for operations on areas of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

120 hp

Max power

160 hp

Weight

5670 kg

Catalogue coverage

Variants represented

Richest spec table

108 rows

Recorded power

120 hp

Recorded weight

5670 kg

Transmissions

24-speed six-speed power shift

Production years

2014-2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

Original price was $152,880 in 2014 with Dyna-VT, DeluxeReference

Final drivesinboard planetaryReference

Differential lockelectro-hydraulic front and rearReference

Steeringhydraulic powerReference

Hydraulic wet disc brakesReference

Cab standard with air conditioning. Optional deluxe cab with mechanical suspension. Optional premium cab with active hydraulic suspension.Reference

Variants

MT495Dsimilar Challenger modelReference

Engine

AGCO Power 4.9L 4-cyl dieselReference

Fuel tank230.9 LReference

Exhaust fluid (DEF)34.8 LReference

Engine111.9 kWReference

AGCO PowerReference

wastegate turbocharger and intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.9 LReference

Bore/Stroke108 x 134 mmReference

EmissionsInterim Tier IVReference

Emission controlslective catalytic reduction with diesel oxidation catalyst (DOC) (SCR)Reference

Power111.9 kWReference

Maximum Power119.3 kWReference

Fuel systemhigh pressure common railReference

Cooling systemelectronically controlled viscous fanReference

Air cleanerdual dry elementReference

Pre-heatingblock heaterReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,200 RPMReference

Bore and stroke4.252x5.276 inchesReference

Transmission

24-speed six-speed power shiftReference

continuously variable transmission (CVT)Reference

TransmissionDyna-6Reference

Typesix-speed power shiftReference

Gears24 forward and reverseReference

Clutchwet discReference

TransmissionDyna-VTReference

Typecontinuously variable transmission (CVT)Reference

Gearsinfinite forward and reverseReference

Transmission TypeCVTReference

Rear Axle Drive Typeinboard planetaryReference

PTO & Hydraulics

PTO (claimed)89.5 kWReference

PTO (claimed)93.2 kWReference

Typeopen centerReference

TypeTwin Flow open center (optional)Reference

Typeclosed center (optional)Reference

Valvesup to 4Reference

SCV flow56.8 lpmReference

SCV flow98.4 lpmReference

SCV flow109.8 lpmReference

Rear TypeIIIReference

Controlelectronic draft controlReference

Rear lift (at 24"/610mm)5171 kgReference

Front lift3197 kgReference

DrawbarCat. 2Reference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Rear PTO Type540E/540/1000/1000EReference

Dimensions

Wheelbase266 cmReference

Weight5670 kgReference

Front tire380/85R28Reference

Rear tire460/85R38Reference

Ag front380/85R28Reference

Ag rear460/85R38Reference

Length469 cmReference

Height (cab)293 cmReference

Front axle4WDReference

Front axleSuspended 4WDReference

Flange rear axleReference

Bar rear axle82 by 2032 mmReference

Bar rear axle94 by 2286 mmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps240 (twin 120A)Reference

Batteries2Reference

Battery CCA600Reference

Battery volts12Reference

Battery options2Reference

Total cold cranking amps600 CCAReference

General

Make & ModelMassey Ferguson (a part of AGCO)Reference

Cruise controlAvailableReference

SCV controlJoystickReference

Drawbar categoryCat. 2Reference

Rear Axle TypeBar : 3.23 by 80 | Bar : 3.74 by 90 inchesReference

Front Axle Type4WD | Suspended 4WDReference

Capacities

Capacity299 ciReference

Diesel exhaust fluid (DEF) tank34.8 LReference

Power

Max Power160 hpReference

Rated Power150 hpReference

PTO

PTO Power125 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Steering & brakes

BrakesHydraulic wet disc brakesReference

Steering typehydraulic powerReference

Hydraulics

Remote Valvesup to 4 valvesReference

Rear Hitch category (SAE designation)Category IIIReference

Rear Hitch Sensing Typeelectronic draft controlReference

Dimensions & weight

Height Over Cab293.4 cmReference

Overall Length469.1 cmReference

Overall weight5,669.9 kgReference

Wheels & tyres

Rear Wheel Type460/85R38Reference

Front Wheel Type380/85R28Reference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
