Tractor · 2017Unverified

Massey Ferguson 6712S

Name: Massey Ferguson 6712S
Brand: Massey Ferguson

Massey Ferguson 6712S — Utility tractor · 105 hp. Reference specifications; pending source verification.

The Massey Ferguson 6712S tractor is rated at 105 hp, placing it in the middle of its class for power. Manufactured from 2017 to 2021, it is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, driving four-wheel drive via a powershift transmission. The listed weight of the tractor is 6999 kg, and it is suited to tasks covering approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

105 hp

Weight

6999 kg

Catalogue coverage

Variants represented

Richest spec table

69 rows

Recorded power

105 hp

Recorded weight

6999 kg

Transmissions

16-speed four-speed power shift

Production years

2017-2021

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Utility tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakespneumaticReference

Trailer brakeshydraulicReference

Cab standard with air-conditioning. Available cab suspension.Reference

Variants

MT455Esimilar Challenger modelReference

Engine

AGCO Power 4.9L 4-cyl dieselReference

Fuel tank253.6 LReference

Exhaust fluid (DEF)29.9 LReference

Engine82.0 kWReference

AGCO Power 49 AWFReference

intercooled turbocharged dieselReference

4-cylinder 16-valveReference

liquid-cooled inlineReference

Displacement4.9 LReference

Bore/Stroke108 x 134 mmReference

EmissionsStage VReference

Emission controlSCR/DEF/DOCReference

Power82.0 kWReference

Maximum Power89.5 kWReference

Fuel systemhigh-pressure common rail direct injectionReference

Rated RPM2100Reference

Torque614.3 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed four-speed power shiftReference

24-speed six-speed power shiftReference

TransmissionDyna-4Reference

Typefour-speed power shiftReference

Gears16 forward and reverseReference

Clutchwet discReference

TransmissionDyna-6Reference

Typesix-speed power shiftReference

Gears24 forward and reverseReference

PTO & Hydraulics

PTO (claimed)78.3 kWReference

Typeopen centerReference

Typeclosed centerReference

Pressure200.0 barReference

Rear valves5Reference

Front valves2Reference

Pump flow99.9 lpmReference

Pump flow110.1 lpmReference

Rear TypeIIIReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540E@1530Reference

Engine RPM540@1980Reference

Engine RPM1000E@1570Reference

Engine RPM1000@2030Reference

Front PTOindependentReference

Front PTO Type1000Reference

Engine RPM1000@1920Reference

Dimensions

Wheelbase266 cmReference

Weight6999 kgReference

Length492 cmReference

Width182 cmReference

Height (cab)302 cmReference

Max weight12500 kgReference

Flange rear axleReference

Bar rear axleReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
