Tractor · 1983Unverified
Massey Ferguson 690T
Massey Ferguson 690T — 600 Series · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Weight
3637 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Built in Beauvais, FranceReference
Original price$29,000 (1986)Reference
Two- or four-wheel driveReference
Final drivesoutboard planetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with available air-conditioning.Reference
Variants
690naturally-aspiratedReference
690TturbochargedReference
Engine
Perkins 4.1L 4-cyl dieselReference
Engine67.1 kWReference
Perkins A4.248Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke101 x 127 mmReference
Power67.1 kWReference
Fuel systemdirect injectionReference
Air cleanerdual paper elementsReference
Compression16:1Reference
Rated RPM2200Reference
Torque324.1 NmReference
Torque RPM1590Reference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Clutch304mm dry discReference
Three gears (1-3), plus reverse gear, in two ranges with additional two-range speedshift. Gears 2-3 and the speedshift are synchronized.Reference
PTO & Hydraulics
Typeopen centerReference
Valves2Reference
Total flow64.3 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)1873 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase228 cmReference
Weight3637 kgReference
Front tire10.00-16Reference
Rear tire16.9-34Reference
Ag front10.00-16 (2WD)Reference
Ag front13.6-24 (4WD)Reference
Ag rear16.9-34 (2WD)Reference
Ag rear18.4-34 (4WD)Reference
Length391 cmReference
Width205 cmReference
Operating weight3637 kgReference
Ballasted weight4669 kgReference
Flange rear axleReference
2WD Front tread137 to 177 cmReference
4WD Front tread160 to 180 cmReference
Rear tread152 to 238 cmReference
690T Serial Numbers
Location:On bottom left of instrument panel.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Speeds
With 15.8-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
