Backhoe Loader · 1969Unverified
Massey Ferguson 70
Massey Ferguson 70 — Backhoe loader tractor · 108 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
108 hp
Weight
8391 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Backhoe loader tractorReference
Two-wheel driveReference
Differential lockhydraulic standardReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Open operator station. Four-post ROPS optional. Cab optional with available heater.Reference
Engine
Perkins 5.2L 4-cyl dieselReference
Engine (gross)80.5 kWReference
Engine (net)62.6 kWReference
Perkins A4.318Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.2 LReference
Bore/Stroke114 x 127 mmReference
Power (net)62.6 kWReference
Power (gross)80.5 kWReference
Air cleanerdryReference
Compression17.5:1Reference
Rated RPM2000Reference
Torque332.2 NmReference
Torque RPM1300Reference
Oil capacity11.8 LReference
Coolant capacity20.8 LReference
Transmission
2-speed full power shift with torque converterReference
Typefull power shift with torque converterReference
Gears2 forward and reverseReference
Oil capacity15.1 LReference
Capacities
Fuel162.8 LReference
PTO & Hydraulics
Hydraulic system208.2 LReference
Typeopen centerReference
Capacity208.2 LReference
Pressure146.5 barReference
Total flow181.7 lpmReference
Total flow113.6 lpmReference
Total flow68.1 lpmReference
Dimensions
Wheelbase228 cmReference
Weight8391 kgReference
Front tire11.00x15Reference
Rear tire16.9x30Reference
Industrial front11.00x15Reference
Industrial rear16.9x30Reference
Industrial front14x17.5-10Reference
Industrial front11.00x16Reference
Industrial rear18.4x28Reference
Length812 cmReference
Width228 cmReference
Height (cab)248 cmReference
Height (backhoe)393 cmReference
Operating8391 kgReference
Max front axle5670 kgReference
Max front axle22680 kgReference
Max rear axle13608 kgReference
Max rear axle40824 kgReference
Backhoe & Loader
Dig depth502 cmReference
Dump angle127 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps32Reference
Batteries2Reference
Battery volts12Reference
Battery AH95Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Massey Ferguson Backhoe
Backhoe typeMassey Ferguson BackhoeReference
Transport height393 cmReference
Digging depth502 cmReference
2-Foot flat digging depth490 cmReference
Reach from pivot640 cmReference
Loading height335 cmReference
Bucket Rotation150°Reference
Swing Arc180°Reference
Bucket force6667 kgReference
Dipperstick force3878 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
