Tractor · 1957Unverified

Massey Ferguson 820

Name: Massey Ferguson 820
Brand: Massey Ferguson

Massey Ferguson 820 — Utility tractor · 20 hp. Reference specifications; pending source verification.

The Massey Ferguson 820 is a tractor model with a rated power of 20 hp, positioned at the lighter end of its class. It was manufactured between 1957 and 1959. The tractor features a 4-cylinder diesel liquid-cooled engine and two-wheel drive, paired with a 5-speed gearbox. Its operating weight is listed at 999 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

999 kg

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

20 hp

Recorded weight

999 kg

Transmissions

5-speed gear

Production years

1957-1959

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Utility tractorReference

Built in Marquette-lez-Lille, FranceReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Engine

Peugeot 1.3L 4-cyl gasolineReference

Hanomag 1.0L 2-cyl dieselReference

Fuel tank29.9 LReference

Engine14.9 kWReference

PeugeotReference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke75 x 73 mmReference

Power14.9 kWReference

Air cleaneroil bathReference

Rated RPM2000Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Oil capacity4.0 LReference

Coolant capacity8.5 LReference

Hanomag D621Reference

dieselReference

2-cylinderReference

Displacement1.0 LReference

Bore/Stroke85 x 90 mmReference

Power13.2 kWReference

Compression18:1Reference

Rated RPM1850Reference

Transmission

5-speed gearReference

TypegearReference

Gears5 forward and 1 reverseReference

Oil capacity7.0 LReference

PTO & Hydraulics

Rear PTOindependentReference

Rear PTO Type540 (1.125)Reference

Engine RPM540@1800Reference

Dimensions

Wheelbase169 cmReference

Weight999 kgReference

Front tire4.00-15Reference

Rear tire9-24Reference

Ag front4.00-15Reference

Ag rear9-24Reference

Ag rear8-24Reference

Ag rear9-28Reference

Length278 cmReference

Width139 cmReference

Height154 cmReference

Ground clearance46 cmReference

Front tread113 to 173 cmReference

Rear tread103 to 175 cmReference

Speeds

With 9-24 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
