Tractor · Unverified
Massey Ferguson 865
Massey Ferguson 865 — Row-Crop tractor · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
1920 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Row-Crop tractorReference
Built in FranceReference
Two-wheel driveReference
Disc brakesReference
Open operator station.Reference
Engine
Perkins 3.3L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine36.5 kWReference
Perkins 203YReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power36.5 kWReference
Compression17.4:1Reference
Rated RPM2000Reference
Starter typeelectricReference
Oil capacity6.0 LReference
Coolant capacity11.4 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Oil capacity30.3 LReference
PTO & Hydraulics
Typeopen centerReference
Pump flow18.2 lpmReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase213 cmReference
Weight1920 kgReference
Front tire6.00x16Reference
Rear tire11x32Reference
Ag front6.00x16Reference
Ag rear11x32Reference
Ag rear13x28Reference
Ag rear11x38 (high clearance)Reference
Length337 cmReference
Width182 cmReference
Height147 cmReference
Front tread121 to 203 cmReference
Rear tread132 to 223 cmReference
Speeds
With 11x32 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
