Snowmobile · 1976Unverified

Massey Ferguson Chinook

Name: Massey Ferguson Chinook
Brand: Massey Ferguson

Massey Ferguson Chinook — Snowmobile · 24 hp. Reference specifications; pending source verification.

The Massey Ferguson Chinook is a snowmobile rated at 24 hp — putting it around the middle of its class for power. It was manufactured in 1976. Power comes from a 2-cylinder petrol air-cooled engine, driving through a tracked undercarriage. Listed weight is 134 kg, and it is aimed at jobs of around up to 200 ac. Detailed specifications in both UK and US units follow below.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

24 hp

Weight

134 kg

Catalogue coverage

Variants represented

Richest spec table

28 rows

Recorded power

24 hp

Production years

1976-1976

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorMassey FergusonReference

ManufacturerScorpionReference

SnowmobileReference

Built in Crosby, Minnesota, USAReference

TrackedReference

Manual steeringReference

Mechanical drum brakesReference

Suspensionbogie wheelReference

Engine

24HP Cuyuna 294cc 2-cyl gasolineReference

Fuel tank18.9 LReference

Cuyuna 295Reference

gasolineReference

2-cylinderReference

air-cooled horizontal-shaft inlineReference

Displacement17.94 ciReference

Bore/Stroke56 x 60 mmReference

Power17.9 kWReference

Fuel systemWalbro carburetorReference

Cooling systemaxial fanReference

Compression12:1Reference

Starter typemanual recoilReference

SparkplugChampion N3Reference

Sparkplug gap0.508 mmReference

Dimensions

Weight134 kgReference

Length233 cmReference

Width88 cmReference

Height (steering)73 cmReference

Track width38 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
