The Massey Ferguson Cyclone 340 is a snowmobile model with a rated output of 40 hp — placing it among the higher-powered machines in its class. This model was produced in 1976. Power comes from a 2-cylinder petrol liquid-cooled engine, driving through a tracked undercarriage. Listed weight is 166 kg, and it is aimed at jobs of around up to 200 ac. See the table below for complete UK and US figures with sourcing.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
166 kg
Catalogue coverage
Variants represented
2
Richest spec table
27 rows
Recorded power
40 hp
Production years
1976-1976
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerScorpionReference
SnowmobileReference
Built in Crosby, Minnesota, USAReference
TrackedReference
Manual steeringReference
Mechanical disc brakesReference
Suspensionslide railReference
Engine
40HP Brooten 335cc 2-cyl gasolineReference
Fuel tank18.9 LReference
Fuel tank30.3 LReference
Brooten LC 34Reference
gasolineReference
2-cylinderReference
liquid-cooled horizontal-shaft inlineReference
Displacement20.5 ciReference
Bore/Stroke62 x 56 mmReference
Power29.8 kWReference
Fuel systemMikuni VM-34 carburetorsReference
Starter typemanual recoilReference
Dimensions
Weight166 kgReference
Length261 cmReference
Width86 cmReference
Height (steering)88 cmReference
Track width39 cmReference
Track length on ground108 cmReference
Track area on ground0.9 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
