Lawn Tractor · 1962Unverified
Massey Ferguson ELF
Massey Ferguson ELF — Garden tractor · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
372 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerGutbrodReference
Garden tractorReference
Built in GermanyReference
Two-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
6.0KW Motosacoche 392cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Motosacoche 1029Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement23.92 ciReference
Bore/Stroke82 x 74 mmReference
Power6.0 kWReference
Air cleaneroil bathReference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 2 reverseReference
Clutchdry discReference
Dimensions
Wheelbase118 cmReference
Weight372 kgReference
Ag front4-8Reference
Ag rear6-12Reference
Length175 cmReference
Width96 cmReference
Ground clearance20 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
