The Massey Ferguson ELF is a lawn tractor model with a rated power of 8 hp, positioning it at the lighter end of its class. Introduced in 1962, the ELF features a 1-cylinder petrol air-cooled engine and a two-wheel drive system coupled with a 4-speed gearbox. The operating weight of the ELF is listed at 372 kg, and it is suitable for operations of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
372 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
8 hp
Recorded weight
372 kg
Transmissions
4-speed gear
Production years
1962-1962
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerGutbrodReference
Garden tractorReference
Built in GermanyReference
Two-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
6.0KW Motosacoche 392cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Motosacoche 1029Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement23.92 ciReference
Bore/Stroke82 x 74 mmReference
Power6.0 kWReference
Air cleaneroil bathReference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 2 reverseReference
Clutchdry discReference
Dimensions
Wheelbase118 cmReference
Weight372 kgReference
Ag front4-8Reference
Ag rear6-12Reference
Length175 cmReference
Width96 cmReference
Ground clearance20 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
