Backhoe Loader · 2008Unverified
Massey Ferguson GC2610
Massey Ferguson GC2610 — GC Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1211 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerIsekiReference
Backhoe loader tractorReference
Original price was $18,203 in 2009Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Iseki 1.1L 3-cyl dieselReference
Engine (gross)18.6 kWReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Power (gross)18.6 kWReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.6 LReference
Coolant capacity4.6 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity11.0 LReference
PTO & Hydraulics
PTO (claimed)14.6 kWReference
Hydraulic system11.0 LReference
Typeopen centerReference
Capacity11.0 LReference
Pump flow18.2 lpmReference
Total flow25.7 lpmReference
Steering flow7.6 lpmReference
Rear TypeIReference
Rear lift (at ends)539 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Capacities
Fuel25.0 LReference
Max capacity1249 kgReference
Dimensions
Wheelbase145 cmReference
Weight1211 kgReference
Front tire18x8.50-10Reference
Rear tire26x12.00-12Reference
Standard tires (ag)Front: 18x8.50-10. Rear: 26x12.00-12Reference
Lawn/turf front18x8.50-10Reference
Lawn/turf rear26x12.00-12Reference
Industrial front18x8.50-10Reference
Industrial rear26x12.00-12Reference
Length449 cmReference
Width136 cmReference
Height (ROPS)218 cmReference
Ground clearance17 cmReference
Front tread92 cmReference
Rear tread83 cmReference
Shipping1211 kgReference
Max front axle879 kgReference
Max rear axle949 kgReference
Backhoe & Loader
Dig depth198 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Massey Ferguson CB05 Backhoe
Backhoe typeMassey Ferguson CB05 BackhoeReference
Digging depth198 cmReference
Reach from pivot259 cmReference
Bucket force884 kgReference
Dipperstick force535 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
