Backhoe Loader · 2008Unverified

Massey Ferguson GC2610

Name: Massey Ferguson GC2610
Brand: Massey Ferguson

Massey Ferguson GC2610 — GC Series · 25 hp. Reference specifications; pending source verification.

The Massey Ferguson GC2610 is a backhoe loader with a rated output of 25 hp, classifying it as one of the more compact options in its class. It was manufactured from 2008 to 2012. The GC2610 features a 3-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system with a hydrostatic transmission. Its listed weight is 1211 kg, making it suitable for tasks on land up to approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

1211 kg

Catalogue coverage

Variants represented

Richest spec table

68 rows

Recorded power

25 hp

Recorded weight

1211 kg

Transmissions

hydrostatic

Production years

2008-2012

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorMassey FergusonReference

ManufacturerIsekiReference

Backhoe loader tractorReference

Original price was $18,203 in 2009Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Iseki 1.1L 3-cyl dieselReference

Engine (gross)18.6 kWReference

Iseki E3112Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Power (gross)18.6 kWReference

Rated RPM3000Reference

StarterelectricReference

Starter volts12Reference

Oil capacity2.6 LReference

Coolant capacity4.6 LReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Oil capacity11.0 LReference

PTO & Hydraulics

PTO (claimed)14.6 kWReference

Hydraulic system11.0 LReference

Typeopen centerReference

Capacity11.0 LReference

Pump flow18.2 lpmReference

Total flow25.7 lpmReference

Steering flow7.6 lpmReference

Rear TypeIReference

Rear lift (at ends)539 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTOindependentReference

Mid PTO Type2000Reference

Capacities

Fuel25.0 LReference

Max capacity1249 kgReference

Dimensions

Wheelbase145 cmReference

Weight1211 kgReference

Front tire18x8.50-10Reference

Rear tire26x12.00-12Reference

Standard tires (ag)Front: 18x8.50-10. Rear: 26x12.00-12Reference

Lawn/turf front18x8.50-10Reference

Lawn/turf rear26x12.00-12Reference

Industrial front18x8.50-10Reference

Industrial rear26x12.00-12Reference

Length449 cmReference

Width136 cmReference

Height (ROPS)218 cmReference

Ground clearance17 cmReference

Front tread92 cmReference

Rear tread83 cmReference

Shipping1211 kgReference

Max front axle879 kgReference

Max rear axle949 kgReference

Backhoe & Loader

Dig depth198 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Massey Ferguson CB05 Backhoe

Backhoe typeMassey Ferguson CB05 BackhoeReference

Digging depth198 cmReference

Reach from pivot259 cmReference

Bucket force884 kgReference

Dipperstick force535 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
