Tractor · 1961Unverified
Massey Ferguson Super 90
Massey Ferguson Super 90 — Row-Crop tractor · 69 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
69 hp
Max power
44.6 kW
Weight
5384 to 7245 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Row-Crop tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Independent dry disc brakesReference
Open operator station.Reference
Engine
Perkins 5.0L 4-cyl dieselReference
Continental 4.0L 4-cyl gasolineReference
Fuel tank106.0 LReference
Engine57.4 kWReference
Diesel Belt (claimed)47.0 kWReference
Gas Belt (claimed)44.7 kWReference
Drawbar (tested)44.6 kWReference
Perkins A4-300Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.0 LReference
Bore/Stroke114 x 121 mmReference
Power57.4 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Compression16:1Reference
Rated RPM2000Reference
Torque302.4 NmReference
Starter volts12Reference
Continental E242Reference
gasolineReference
Displacement4.0 LReference
Bore/Stroke98 x 130 mmReference
Compression7.3:1Reference
Torque287.5 NmReference
Firing order1-3-4-2Reference
Power at rated engine speed51.1 kWReference
Max power44.6 kWReference
Transmission
8-speed gearReference
16-speed two-speed power shiftReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
Four gears (1-4), plus reverse (R), in two ranges.Reference
TransmissionMulti-PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
PTO (tested)51.1 kWReference
Pump flow7.6 lpmReference
Total flow17.0 lpmReference
Rear PTOliveReference
Clutchwet discReference
Rear PTO Type540 (1.375)Reference
Power at rated PTO speed43.0 kWReference
Dimensions
Wheelbase223 cmReference
Weight5384 to 7245 poundsReference
Front tire7.50-16Reference
Rear tire18.4/15-30Reference
Ag front7.50-16Reference
Ag rear18.4/15-30Reference
Ag front6.50-16Reference
Ag rear13.6/12-38Reference
Length341 cmReference
Height176 cmReference
Gas Shipping2442 kgReference
Diesel Shipping2602 kgReference
Operating3286 kgReference
Ballasted5704 kgReference
Massey Ferguson Super 90 attachments
front-end loaderReference
Super 90 Serial Number Location
Right side of tractor, just ahead of operator platform.Reference
Super 90 Serial Numbers
1961810000Reference
1962810393Reference
1963813385Reference
1964816867Reference
1965819763Reference
FAQ: How to read a serial number table.Reference
Test results
Diesel 8-speed 2WDJune 12 - 21, 1962Link: Nebraska Tractor Test 822 fileReference
PTO performanceReference
Fuel use16.3 l/hourReference
Fuel use13.2 l/hourReference
Drawbar performanceReference
Gear 3 used for power test.Reference
Max pull4228 kgReference
Gear 2 used for pull test.Reference
Speeds
With 18.4/15-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
