Industrial Tractor · 1958Unverified

Massey Ferguson Work Bull 202

Name: Massey Ferguson Work Bull 202
Brand: Massey Ferguson

Massey Ferguson Work Bull 202 — Work Bull Series · 40 hp. Reference specifications; pending source verification.

The Massey Ferguson Work Bull 202 is an industrial tractor with a rated output of 40 hp, featuring a compact design suitable for its class. It was manufactured from 1958 to 1967. The tractor is equipped with a 4-cylinder diesel liquid-cooled engine, coupled with a 6-speed gearbox and two-wheel drive. Its listed weight is 1388 kg, making it suitable for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

1388 kg

Catalogue coverage

Variants represented

Richest spec table

102 rows

Recorded power

40 hp

Recorded weight

1388 kg

Transmissions

6-speed gear

Production years

1958-1967

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Industrial tractorReference

Two-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Mechanical drum brakesReference

Open operator station.Reference

Variants

202gas gearReference

203diesel gearReference

204gas torque converterReference

205diesel torque converterReference

35farm tractorReference

Engine

Continental 2.2L 4-cyl gasolineReference

Engine (net)29.8 kWReference

Continental Z-134Reference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke84 x 98 mmReference

Power (net)29.8 kWReference

Fuel systemupdraft carburetorReference

Compression6.6:1Reference

Rated RPM2000Reference

Torque146.4 NmReference

Torque RPM1200Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Transmission

6-speed gearReference

6-speed mechanical shuttleReference

TypegearReference

Gears6 forward and 2 reverseReference

Clutchdry discReference

Three gears (1-3) plus reverse (R) in two ranges (low/high).Reference

Typemechanical shuttleReference

Gears6 forward and reverseReference

Three gears (1-3) in two ranges (low/high) with manual shuttle shift.Reference

PTO & Hydraulics

Typeopen centerReference

Pressure193.1 barReference

Pump flow15.1 lpmReference

Steering flow15.1 lpmReference

Steering press.75.8 barReference

Rear TypeIReference

Rear PTOtransmissionReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1500Reference

Dimensions

Wheelbase190 cmReference

Weight1388 kgReference

Rear tire14.9-24Reference

Ag front7.50-16Reference

Ag rear14.9/13-24Reference

Lawn/turf rear14.9/13-24Reference

Industrial rear14.9-24Reference

Length299 cmReference

Width167 cmReference

Height (steering wheel)135 cmReference

Shipping weight1388 kgReference

Ground clearance33 cmReference

Front tread167 cmReference

Rear tread121/132/142/152/162/172/182/193 cmReference

Massey Ferguson 202 attachments

front-end loaderReference

backhoeReference

202 Serial Numbers

1958301172Reference

1959303158Reference

1960305108Reference

1961306169Reference

1962306779Reference

1963307923Reference

1964309222Reference

1965310067Reference

1966311084Reference

19679A1001Reference

FAQ: How to read a serial number table.Reference

Attachment overview

Massey Ferguson 99 loaderReference

Massey Ferguson 101 loaderReference

Massey Ferguson 102 loaderReference

BackhoeReference

Massey Ferguson 185 Backhoe

Backhoe typeMassey Ferguson 185 BackhoeReference

Transport height279 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width50 cmReference

Bucket width60 cmReference

Digging depth350 cmReference

Reach from pivot530 cmReference

Loading height259 cmReference

Swing Arc180°Reference

Bucket force3288 kgReference

Massey Ferguson 220 Backhoe

Backhoe typeMassey Ferguson 220 BackhoeReference

Transport height279 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width50 cmReference

Bucket width60 cmReference

Digging depth350 cmReference

Reach from pivot530 cmReference

Loading height259 cmReference

Swing Arc200°Reference

Bucket force4037 kgReference

Speeds

With 14.9x24 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
