Lawn Tractor · 2002Unverified
Massey Ferguson ZT 1638
Massey Ferguson ZT 1638 — ZT Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
263 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerSimplicityReference
Zero-turn mowerReference
Built in Port Washington, Wisconsin, USAReference
Two-wheel driveReference
Steeringhydrostatic differentialReference
Open operator station.Reference
Variants
ZT16similar Simplicity modelReference
Engine
16HP Kohler 1-cyl gasolineReference
Fuel tank7.6 LReference
Kohler CommandReference
gasolineReference
1-cylinderReference
air-cooledReference
Power (gross)11.9 kWReference
Rated RPM3400Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Wheelbase111 cmReference
Weight263 kgReference
Front tire13x5.0-6Reference
Rear tire18x9.5-8Reference
Lawn/turf front13x5.0-6Reference
Lawn/turf rear18x9.5-8Reference
Length156 cmReference
Width104 cmReference
Height (steering wheel)110 cmReference
Weight263 kgReference
Massey Ferguson ZT 1638 attachments
38" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
38" Mower deck
Typemid-mount Massey FergusonReference
Type2-bladeReference
Cutting width96 cmReference
Overall width125 cmReference
Cut height3 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
