Tractor · 1946Unverified

Massey-Harris 20 Standard

Name: Massey-Harris 20 Standard
Brand: Massey-Harris

Massey-Harris 20 Standard — Standard-tread tractor · 31 hp. Reference specifications; pending source verification.

The Massey-Harris 20 Standard is a tractor model with a rated output of 31 hp — making it one of the more compact options in its class. This model was produced from 1946 to 1948. Power comes from a 4-cylinder petrol liquid-cooled engine, driving through two-wheel drive with a 4-speed gearbox. It is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

31 hp

Catalogue coverage

Variants represented

Richest spec table

39 rows

Recorded power

31 hp

Transmissions

4-speed gear

Production years

1946-1948

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMassey-HarrisReference

Standard-tread tractorReference

Built in Racine, Wisconsin, USAReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Variants

20 RCrow-cropReference

20 STDstandard treadReference

Engine

Continental 2.0L 4-cyl gasolineReference

Continental 2.3L 4-cyl keroseneReference

Belt (claimed)23.1 kWReference

Plows2Reference

Continental F124Reference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke76 x 111 mmReference

Rated RPM1500Reference

Rated RPM1800Reference

Coolant capacity10.4 LReference

Continental F140Reference

keroseneReference

Displacement2.3 LReference

Bore/Stroke81 x 111 mmReference

Air cleaneroil bathReference

Transmission

4-speed gearReference

TypegearReference

Gears4 forward and 1 reverseReference

Clutchdry discReference

PTO & Hydraulics

Rear PTO Type550Reference

20 Serial Numbers

19461001 (gas)Reference

19471002 (gas)Reference

19482230 (gas)Reference

19471001 (kerosene)Reference

19481819 (kerosene)Reference

FAQ: How to read a serial number table.Reference

Dimensions

Width208 cmReference

Height193 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
