Tractor · 1948Unverified
Massey-Harris 22 Standard
Massey-Harris 22 Standard — Standard-tread tractor · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Max power
17.1 kW
Weight
1229 kg
Hover a source tag to verify
Overview
ManufacturerMassey-HarrisReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
22 RCrow-cropReference
22 STDstandard treadReference
Engine
Continental 2.3L 4-cyl gasolineReference
Drawbar (claimed)13.4 kWReference
Plows2Reference
Drawbar (tested)17.1 kWReference
Belt (tested)23.2 kWReference
ContinentalReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke81 x 111 mmReference
Rated RPM1500Reference
Oil capacity4.7 LReference
Coolant capacity10.4 LReference
Belt power (max)23.2 kWReference
Max power17.1 kWReference
Transmission
4-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)20.1 kWReference
Hydraulic system6.6 LReference
Capacity6.6 LReference
Pump flow28.4 lpmReference
Rear PTO Type540Reference
Capacities
Fuel49.2 LReference
Dimensions
Wheelbase189 cmReference
Weight1229 kgReference
Front tire5x15Reference
Rear tire10x28Reference
Ag front5x15Reference
Ag rear10x28Reference
Front tread116 cmReference
Rear tread121 cmReference
22 Serial Number Location
Left side of tractor frame.Reference
22 Serial Numbers
19481001Reference
19491542Reference
19503208Reference
19514533Reference
19525717Reference
195320046Reference
FAQ: How to read a serial number table.Reference
Test results
Gasoline 4-speed 2WDOctober 15 - 21, 1948Link: Nebraska Tractor Test 403 fileReference
Belt fuel use (max)10.6 l/hourReference
Drawbar performanceReference
Gear 3 used for power test.Reference
Max pull1271 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
