Tractor · 1948Unverified
Massey-Harris 744
Massey-Harris 744 · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Hover a source tag to verify
Overview
ManufacturerMassey-HarrisReference
FactoriesManchester, EnglandReference
FactoriesKilmarnock, ScotlandReference
Total built17,000Reference
The Massey-Harris 744PD was a British-built version of the 44. The 744 was fitted with a Perkins diesel engine in place of the Continental engine in the North American market.Reference
Two-wheel driveReference
Open operator station.Reference
Variants
744PDEnglish-builtReference
744DScottish-builtReference
Engine
Perkins 4.7L 6-cyl dieselReference
Engine34.3 kWReference
Drawbar (claimed)29.1 kWReference
Belt (claimed)31.3 kWReference
Perkins P6Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement4.7 LReference
Bore/Stroke89 x 127 mmReference
Power34.3 kWReference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
