Tractor · 1941Unverified

Massey-Harris 81 Standard

Name: Massey-Harris 81 Standard
Brand: Massey-Harris

Massey-Harris 81 Standard — Standard-tread tractor · 26 hp. Reference specifications; pending source verification.

The Massey-Harris 81 Standard is a tractor with a rated power output of 26 hp, categorising it as a lighter model in its class. Manufactured from 1941 to 1946, it features a 4-cylinder petrol liquid-cooled engine paired with two-wheel drive and a 4-speed gearbox. This tractor is suitable for operations spanning up to 200 acres. Details of the UK and US specifications are provided.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

26 hp

Catalogue coverage

Variants represented

Richest spec table

41 rows

Recorded power

26 hp

Transmissions

4-speed unsynchronized gear

Production years

1941-1946

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMassey-HarrisReference

Standard-tread tractorReference

Two-wheel driveReference

SteeringmanualReference

Open operator station.Reference

Variants

81Rrow-crop gasolineReference

81Sstandard gasolineReference

82distillateReference

Engine

Continential 2.0L 4-cyl gasolineReference

Fuel tank45.4 LReference

Drawbar (claimed)11.9 kWReference

Continential F124Reference

gasolineReference

4-cylinderReference

liquid-cooled vertical L-headReference

Displacement2.0 LReference

Bore/Stroke76 x 111 mmReference

Fuel systemMarvel-Schebler TSX-28 carburetorReference

Rated RPM1500Reference

Starter volts6Reference

Coolant capacity10.4 LReference

Transmission

4-speed unsynchronized gearReference

Typeunsynchronized gearReference

Gears4 forward and 1 reverseReference

Clutchdry discReference

PTO & Hydraulics

PTO (claimed)19.4 kWReference

Dimensions

Front tire4.00x15Reference

Rear tire9.00x32Reference

Ag front4.00x15Reference

Ag rear9.00x32Reference

Length302 cmReference

Height147 cmReference

81 Standard Serial Numbers

Location:Left side of tractor frame.Reference

1941400001Reference

1942403168Reference

1943------Reference

1944403354Reference

1945403364Reference

1946404664Reference

Final406601Reference

FAQ: How to read a serial number table.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
