Tractor · 1947Unverified
Massey-Harris Pony 11
Massey-Harris Pony 11 — Utility tractor · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Max power
7.8 kW
Weight
1450 to 1890 pounds
Hover a source tag to verify
Overview
ManufacturerMassey-HarrisReference
Utility tractorReference
Built in Woodstock, Ontario, CanadaReference
Two-wheel driveReference
Final drivesbull gearReference
Manual steeringReference
Differential mechanical contracting band brakesReference
Open operator station.Reference
Variants
Pony 14industrial tractorReference
Engine
Continental 1.0L 4-cyl gasolineReference
Plows1Reference
Drawbar (tested)7.8 kWReference
Belt (tested)8.7 kWReference
Continental N62Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke60 x 89 mmReference
Air cleaneroil bathReference
Compression6.5:1Reference
Rated RPM1800Reference
Oil capacity3.8 LReference
Coolant capacity6.6 LReference
SparkplugChampion 18625AReference
Belt power (max)8.7 kWReference
Max power7.8 kWReference
Transmission
3-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears3 forward and 1 reverseReference
Clutchmechanical dry discReference
Oil capacity3.4 LReference
Capacities
Fuel26.5 LReference
Diameter15 cmReference
Width13 cmReference
RPM1990Reference
Speed1005.84 meters/minReference
PTO & Hydraulics
Hydraulic system1.5 LReference
TypeoptionalReference
Capacity1.5 LReference
Pump flow9.5 lpmReference
Rear PTOoptionalReference
Rear PTO Type540Reference
Dimensions
Wheelbase167 cmReference
Weight1450 to 1890 poundsReference
Front tire4.00x-15Reference
Rear tire8-24Reference
Ag front4.00x-15Reference
Ag rear8-24Reference
Ag rear9-24Reference
Height152 cmReference
Front tread114 to 191 cmReference
Rear tread104 to 182 cmReference
Shipping657 kgReference
Operating857 kgReference
Ballasted1155 kgReference
Massey-Harris Pony 11 attachments
bladeReference
Pony 11 Serial Number Location
Serial number on the right-front side of the tractor frame.Reference
Pony 11 Serial Numbers
1947PGS1001Reference
1948PGS1321Reference
1949PGS1571Reference
1947PGA1001Reference
1948PGA1001AReference
1949PGA1571AReference
1950PGA10817AReference
1951PGA13726Reference
1952PGA18225Reference
1953PGA22007Reference
1954PGA22669Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemgeneratorReference
Test results
Gasoline 3-speed 2WDSeptember 14 - 22, 1948Link: Nebraska Tractor Test 401 fileReference
Belt fuel use (max)4.5 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull649 kgReference
Gear 1 used for pull test.Reference
Speeds
With 8-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
