Lawn Tractor · 1949Unverified
Mayrath Standard
Mayrath Standard — Garden tractor · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
238 kg
Hover a source tag to verify
Overview
ManufacturerMayrathReference
Garden tractorReference
Built in Dodge City, Kansas, USAReference
Original price was $349 in 1950Reference
Two-wheel driveReference
Manual steeringReference
Open operator station with steel pan seat.Reference
Engine
8.25HP Briggs & Stratton 376cc 1-cyl gasolineReference
Briggs & Stratton 23Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement23 ciReference
Bore/Stroke76 x 83 mmReference
Power6.2 kWReference
Rated RPM3200Reference
Starter typemanual rope recoilReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Dimensions
Wheelbase127 cmReference
Weight238 kgReference
Ag front5x16Reference
Ag rear5x16Reference
Shipping weight238 kgReference
Ground clearance25 cmReference
Front tread93 cmReference
Rear tread93 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
