Tractor · 2001Unverified
McConnell-Marc 425
McConnell-Marc 425 — Compact Utility tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1539 kg
Hover a source tag to verify
Overview
DistributorMcConnell-MarcReference
ManufacturerTaishanReference
Compact Utility tractorReference
Built in ChinaReference
The McConnell-Marc 425 is similar to the Taishan TS254.Reference
Four-wheel driveReference
Power steeringReference
Drum brakesReference
Two-post ROPS.Reference
Engine
Fei Dong 1.6L 2-cyl dieselReference
Engine17.6 kWReference
Fei Dong 295TReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke95 x 115 mmReference
Power17.6 kWReference
Rated RPM2000Reference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase175 cmReference
Weight1539 kgReference
Front tire6.00-16Reference
Rear tire9.50-24Reference
Ag front6.00-16Reference
Ag rear9.50-24Reference
Length304 cmReference
Height226 cmReference
Shipping weight1539 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
