The McConnell-Marc 425XL is a tractor with a rated output of 28 hp, categorising it as a compact option within its class. This model was manufactured from 2001 to 2005 and features a 3-cylinder diesel liquid-cooled engine, which powers a 4-wheel drive system via a 6-speed gearbox. The listed weight of the 425XL is 1179 kg, and it is suited for tasks covering areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1179 kg
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
28 hp
Recorded weight
1179 kg
Transmissions
6-speed gear
Production years
2001-2005
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorMcConnell-MarcReference
ManufacturerJinmaReference
Compact Utility tractorReference
Built in ChinaReference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post ROPS.Reference
Engine
Yangdong 1.5L 3-cyl dieselReference
Engine20.9 kWReference
Yangdong Y385Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke85 x 90 mmReference
Power20.9 kWReference
Rated RPM2600Reference
Firing order1-3-2Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase165 cmReference
Weight1179 kgReference
Front tire6.00-16Reference
Rear tire9.50-24Reference
Ag front6.00-16Reference
Ag rear9.50-24Reference
Length279 cmReference
Height208 cmReference
Shipping weight1179 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
