Tractor · 2001Unverified
McConnell-Marc 450
McConnell-Marc 450 — Compact Utility tractor · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2766 kg
Hover a source tag to verify
Overview
DistributorMcConnell-MarcReference
ManufacturerJaingsuReference
Compact Utility tractorReference
Built in ChinaReference
The McConnell-Marc 450 is similar to the Jiangsu 504.Reference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post ROPS.Reference
Engine
Yangzhou 3.3L 4-cyl dieselReference
Engine37.3 kWReference
Yangzhou 495TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke95 x 115 mmReference
Power37.3 kWReference
Rated RPM2000Reference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Wheelbase208 cmReference
Weight2766 kgReference
Front tire9.50-24Reference
Rear tire14.9-28Reference
Ag front9.50-24Reference
Ag rear14.9-28Reference
Length359 cmReference
Height233 cmReference
Shipping weight2766 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
