The McConnell-Marc 450 is a tractor with a rating of 50 hp, categorising it as one of the more compact models in its class. Manufactured from 2001 to 2005, this tractor features a 4-cylinder diesel liquid-cooled engine and four-wheel drive with an 8-speed gearbox. Its listed weight is 2766 kg, with an intended application for areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2766 kg
Catalogue coverage
Variants represented
2
Richest spec table
35 rows
Recorded power
50 hp
Recorded weight
2766 kg
Transmissions
8-speed gear
Production years
2001-2005
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorMcConnell-MarcReference
ManufacturerJaingsuReference
Compact Utility tractorReference
Built in ChinaReference
The McConnell-Marc 450 is similar to the Jiangsu 504.Reference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post ROPS.Reference
Engine
Yangzhou 3.3L 4-cyl dieselReference
Engine37.3 kWReference
Yangzhou 495TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke95 x 115 mmReference
Power37.3 kWReference
Rated RPM2000Reference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Wheelbase208 cmReference
Weight2766 kgReference
Front tire9.50-24Reference
Rear tire14.9-28Reference
Ag front9.50-24Reference
Ag rear14.9-28Reference
Length359 cmReference
Height233 cmReference
Shipping weight2766 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
