Tractor · 1937Unverified
McCormick-Deering T-35
McCormick-Deering T-35 — Agricultural Crawler tractor · 29 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Max power
26.1 kW
Weight
4558 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick-Deering (a part of International Harvester)Reference
Agricultural Crawler tractorReference
Total built5,586Reference
DrivecrawlerReference
Variants
T-35gasolineReference
TD-35dieselReference
Engine
International Harvester 4.6L 6-cyl gasolineReference
International Harvester 4.6L 6-cyl distillateReference
Fuel tank151.4 LReference
Aux. fuel4.7 LReference
Drawbar (claimed)21.6 kWReference
Belt (claimed)29.1 kWReference
Drawbar (tested)26.8 kWReference
Belt (tested)33.1 kWReference
International HarvesterReference
gasolineReference
6-cylinderReference
liquid-cooled vertical I-headReference
Displacement4.6 LReference
Bore/Stroke92 x 114 mmReference
Rated RPM1750Reference
Coolant capacity45.4 LReference
distillateReference
liquid-cooledReference
Belt power (max)31.5 kWReference
Max power26.1 kWReference
Belt power (max)33.1 kWReference
Max power26.8 kWReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Dimensions
Weight4558 kgReference
13-inch tracksReference
T-35 Serial Numbers
Location:Seat, right sideReference
McCormick-Deering T-35 Tracks
Width33 cmReference
Test results
NTTL 278: distillateReference
NTTL 279: gasolineReference
Distillate April 1937Reference
Drawbar performanceReference
Gasoline May 1937Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
