Tractor · 1938Unverified
McCormick-Deering W-14
McCormick-Deering W-14 — Standard-tread tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
1496 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick-Deering (a part of International Harvester)Reference
Standard-tread tractorReference
Built in Chicago, Illinois, USAReference
Total built1,163Reference
Two-wheel driveReference
Open operator station.Reference
Variants
F-14Farmall row-crop versionReference
O-14orchardReference
I-14industrialReference
Engine
International Harvester 1.9L 4-cyl gasolineReference
Fuel tank41.6 LReference
Drawbar (claimed)11.0 kWReference
Belt (claimed)13.0 kWReference
Plows1Reference
International HarvesterReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Bore/Stroke76 x 102 mmReference
Fuel systemIH A-10 carburetorReference
Rated RPM1650Reference
Starter typehand-crankReference
Coolant capacity11.4 LReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type550Reference
Dimensions
Wheelbase152 cmReference
Weight1496 kgReference
Front tire5.50x16Reference
Rear tire9.00x24Reference
Ag front5.50x16Reference
Ag rear9.00x24Reference
Ag rear11.25x24Reference
W-14 Length261 cmReference
O-14 Length289 cmReference
W-14 Width127 cmReference
O-14 Width157 cmReference
O-14 Height (hood)121 cmReference
Front tread100 cmReference
Rear tread106 cmReference
W-14 Serial Numbers
Location:Front of fuel tank support.Reference
19384134Reference
19394610Reference
Final5296Reference
19383261 (O-14, Fairway 14)Reference
19393882 (O-14, Fairway 14)Reference
Final4287 (O-14, Fairway 14)Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter31 cmReference
Width15 cmReference
RPM794Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
