Tractor · 2011Unverified
McCormick Intl B105 Max
McCormick Intl B105 Max — B-Max Series · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
3442 kg
Hover a source tag to verify
Overview
ManufacturerMcCormick Intl (a part of Argo)Reference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Differential lockhydraulic front and rearReference
Mechanical wet disc brakesReference
Trailer brakeshydraulicReference
Two-post ROPS. Available canopy.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine73.5 kWReference
Perkins 1104D-44TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsTier IIIReference
Power73.5 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression18.2:1Reference
Rated RPM2200Reference
Torque383.7 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
12-speed mechanical shuttleReference
24-speedReference
TransmissionSpeed FourReference
Gears12 forward and 4 reverseReference
Clutch304.8mm mechanical dry discReference
Four gears in three ranges.Reference
TransmissionSpeed Four shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
TransmissionSpeed Four creeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)67.9 kWReference
Pressure180.0 barReference
Valves1 or 2Reference
SCV flow52.2 lpmReference
Total flow76.5 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2600 kgReference
Rear lift4350 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type540/750 (1.375)Reference
Dimensions
2WD Wheelbase236 cmReference
4WD Wheelbase233 cmReference
Weight3442 kgReference
Front tire12.4-24Reference
Rear tire18.4-30Reference
Standard tires (ag)Front: 12.4-24. Rear: 18.4-30Reference
2WD Optional tires (ag)Front: 7.50-20. Rear: 18.4-30Reference
4WD Optional tires (ag)Front: 380/70R24. Rear: 480/70R34Reference
4WD Optional tires (ag)Front: 420/70R24. Rear: 520/70R34Reference
4WD Optional tires (ag)Front: 440/65R24. Rear: 540/65R34Reference
4WD Optional tires (ag)Front: 12.4R24. Rear: 13.6R38Reference
4WD Optional tires (ag)Front: 340/85R24. Rear: 420/85R34Reference
4WD Optional tires (ag)Front: 11.2R24. Rear: 13.6R36Reference
4WD Optional tires (ag)Front: 13.6R24. Rear: 480/70R34Reference
4WD Optional tires (ag)Front: 320/70R24. Rear: 16.9R30Reference
4WD Optional tires (ag)Front: 14.9R24. Rear: 18.4R34Reference
4WD Optional tires (ag)Front: 405/70R20. Rear: 540/65R30Reference
Length416 cmReference
Width206 cmReference
4WD Ground clearance40 cmReference
Front tread154 to 195 cmReference
Rear tread160 to 200 cmReference
Steering wheel177 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
McCormick Intl B105 Max Height
Hood166 cmReference
ROPS254 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
